Chapter 3: Configuration
For Windows XP
From the Start menu, point to Control
Panel and then click Network and
Internet Connections.
Click Network Connection and then
click Properties.
Click Network Connection and then
click Properties.3. On the General tab,
check out the list of installed network
components.
Option 1: If you have no TCP/IP
Protocol, click Install.
Option 2: If you have TCP/IP Protocol,
go to Step 6.
Highlight Protocol and then click Add.
Click Internet Protocol(TCP/IP) and
then click OK.
On the Local Area Connection
Properties window, highlight Internet
Protocol (TCP/IP) and then click
Properties.
Under the General tab, enable Use the
following IP address. Enter the IP
address: 10.0.0.x (x is between 1 and
100), Subnet Mask: 255.255.255.0 and
Default gateway: 10.0.0.138. Then click
Ok.
10. 0. 0. 100
10. 0. 0. 138
15
