Installation and
Operation
This sections details the installation of the FOX USB Extender, including:
•
•
•
•
Mounting Overview
The 3 inches deep, 1 inch high, quarter rack width FOX USB Extender transmitter and
receiver can be placed on a tabletop, behind a display, mounted on a rack shelf, or mounted
under a desk or tabletop. The receiver can be mounted on a projector bracket.
Mounting details are included in
Information" section on page 12. Mounting instructions are included with each optional
mounting kit.
ATTENTION: Installation and service must be performed by authorized personnel only.
Mounting Overview
Connections
System Startup and Operation
Troubleshooting
"Mounting the FOX USB
FOX USB Extender • Installation and Operation
Extender" in the "Reference
4
