General
Power supply .................................. External
Power consumption
Device
FOX USB Extender Tx ......... 2.6 watts
FOX USB Extender Rx ......... 11.5 watts
Device and power supply
FOX USB Extender Tx ......... 3.4 watts
FOX USB Extender Rx ......... 13.9 watts
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, vents on top and sides
Thermal dissipation
Device
FOX USB Extender Tx ......... 8.8 BTU/hr
FOX USB Extender Rx ......... 10.1 BTU/hr
Device and power supply
FOX USB Extender Tx ......... 11.4 BTU/hr
FOX USB Extender Rx ......... 18.3 BTU/hr
Mounting
Rack mount ............................. Yes, with optional rack shelf or rack mounting brackets
Furniture or wall mount ........... Yes, with optional mounting kits
Enclosure type ................................ Metal
Enclosure dimensions ..................... 1.0" H x 4.3" W x 3.0" D
Product weight ............................... 0.25 lbs (0.1 kg)
Shipping weight ............................. 1 lb (<1 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI Class A
Environmental .......................... Complies with the appropriate requirements of RoHS, WEEE
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTES:
• All nominal levels are at ±10%.
Specifications are subject to change without notice.
•
Input: 100-240 VAC, 50-60 Hz
Output: 12 VDC, 1 A, 12 watts
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
(2.5 cm H x 10.9 cm W x 7.6 cm D)
(Depth excludes connectors.)
FOX USB Extender • Reference Information 10
