5. Configuration Using Web Manager

You must configure the unit so that it can communicate on a network with your serial device.
For example, you must set the way the unit will respond to serial and network traffic, how it
will handle serial packets, and when to start or close a connection.
The unit's configuration is stored in nonvolatile memory and is retained without power. You
can change the configuration at any time. The unit performs a reset after you change and
store the configuration.
In this chapter, we describe how to configure the Micro125 using Web-Manager, Lantronix's
browser-based configuration tool. (For information on using Setup Mode, our command line
configuration interface, see
Note: The examples in this section show a typical device. Your device may have different
configuration options.

Accessing Web-Manager Using DeviceInstaller

Note: For more information on DeviceInstaller, see
1. Run DeviceInstaller and search for the list of available Lantronix device servers.
2. Click on the Micro folder. The list of available Micro type devices displays.
3. Expand the list of Micro125 devices by clicking the + symbol next to the Micro125 icon.
4. Select the Micro125 unit by clicking its hardware address.
5. In the right pane, click the Web Configuration tab.
6. To view the Micro125's Web-Manager in the current DeviceInstaller window, click the Go
button. To open the Web-Manager in a web browser, click the External Browser button.
Note: Alternatively, to open Web-Manager, open your web browser and enter the IP address
of the Micro125.
A dialog box appears to prompt for a User name and Password.
Micro125 User Guide
Chapter 6: Configuration via Telnet or Serial Port (Setup Mode).
Chapter 4: Using DeviceInstaller.
18
