Figure 21 Broadband Add/Edit: Bridge
The following table describes the fields in this screen.
Table 8 Broadband Add/Edit: Bridge
LABEL
General
Name
Mode
Enable VLAN
Enter 802.1P
Priority
Enter 802.1Q VLAN
ID
Enable VLAN on
LAN side
Apply
Back

5.3 The 3G Backup Screen

Use this screen to configure your 3G settings. Click Broadband > 3G Backup.
At the time of writing, the 3G card you can use in the Device is Huawei E220, E270, E160, E169G.
Note: The actual data rate you obtain varies depending the 3G card you use, the signal
strength to the service provider's base station, and so on.
If the signal strength of a 3G network is too low, the 3G card may switch to an available 2.5G or
2.75G network. Refer to
wireless technologies.
FMG3024-D10A / FMG3025-D10A Series User's Guide
DESCRIPTION
Enter a service name of the connection.
Select Bridge when your ISP provides you more than one IP address and you
want the connected computers to get individual IP address from ISP's DHCP
server directly. If you select Bridge, you cannot use routing functions, such as
QoS, Firewall, DHCP server and NAT on traffic from the selected LAN port(s).
Select this to add the VLAN Tag (specified below) to the outgoing traffic
through this connection.
Specific LAN ports can be selected on the Interface Group screen
on page 143).
IEEE 802.1p defines up to 8 separate traffic types by inserting a tag into a
MAC-layer frame that contains bits to define class of service.
Type the IEEE 802.1p priority level (from 0 to 7) to add to traffic through this
connection. The greater the number, the higher the priority level.
Type the VLAN ID number (from 1 to 4094) for traffic through this connection.
Select this to have the Device add a VLAN tag to outgoing packets on the LAN
ports.
Click Apply to save your changes.
Click Back to return to the previous screen.
Section 5.4 on page 83 for a comparison between 2G, 2.5G, 2.75G and 3G
Chapter 5 Broadband
(Section 12.2
81
