Chapter 19 Logs
Table 66 Syslog Severity Levels
CODE SEVERITY
3 Error: There is an error condition on the system.
4 Warning: There is a warning condition on the system.
5 Notice: There is a normal but significant condition on the system.
6 Informational: The syslog contains an informational message.
7 Debug: The message is intended for debug-level purposes.

19.2 The System Log Screen

Click System Monitor > Log to open the System Log screen. Use the System Log screen to see
the system logs for the categories that you select in the upper left drop-down list box.
Figure 103 System Monitor > Log > System Log
The following table describes the fields in this screen.
Table 67 System Monitor > Log > System Log
LABEL
Level
Refresh
Clear Log
#
Time
Level
Messages
206
DESCRIPTION
Select a severity level from the drop-down list box. This filters search results
according to the severity level you have selected. When you select a severity, the
Device searches through all logs of that severity or higher.
Click this to renew the log screen.
Click this to delete all the logs.
This field is a sequential value and is not associated with a specific entry.
This field displays the time the log was recorded.
This field displays the severity level of the logs that the device is to send to this
syslog server.
This field states the reason for the log.
FMG3024-D10A / FMG3025-D10A Series User's Guide
