Chapter 20 Traffic Status
Figure 109 System Monitor > Traffic Status > 3G Backup
The following table describes the fields in this screen.
Table 73 System Monitor > Traffic Status > 3G backup
LABEL
Status
Refresh Interval
Connected
Interface
Packets Sent
Data
Error
Drop
Packets Received
Data
Error
Drop
20.6 The VoIP Status Screen
Click System Monitor > VoIP Status to open the following screen. You can view the VoIP traffic
statistics in this screen.
212
DESCRIPTION
This shows the number of bytes received and sent through the 3G interface of the
Device.
Select how often you want the Device to update this screen from the drop-down
list box.
This shows the name of the 3G connection interface that is currently connected.
This indicates the number of transmitted packets on this interface.
This indicates the number of frames with errors transmitted on this interface.
This indicates the number of outgoing packets dropped on this interface.
This indicates the number of received packets on this interface.
This indicates the number of frames with errors received on this interface.
This indicates the number of received packets dropped on this interface.
FMG3024-D10A / FMG3025-D10A Series User's Guide
