Each field is described in the following table.
Table 40 Security > Firewall > Access Control
LABEL
Add new ACL rule
Name
Src IP
Dst IP
Services
Policy
Modify

13.4.1 The Add New ACL Rule/Edit Screen

Click Add New ACL Rule or the Edit icon next to an existing ACL rule in the Access Control
screen. The following screen displays.
Figure 73 Security > Firewall > Access Control > Add New ACL Rule/Edit
FMG3024-D10A / FMG3025-D10A Series User's Guide
DESCRIPTION
Click this to go to add a filter rule for incoming or outgoing IP traffic.
This displays the name of the rule.
This displays the source IP addresses to which this rule applies. Please note that a blank
source address is equivalent to Any.
This displays the destination IP addresses to which this rule applies. Please note that a
blank destination address is equivalent to Any.
This displays the protocol type and a port range that define the service to which this rule
applies.
This field displays whether the rule silently discards packets (DROP), discards packets
and sends a TCP reset packet or an ICMP destination-unreachable message to the sender
(REJECT) or allows the passage of packets (PERMIT).
Click the Edit icon to edit the rule.
Click the Delete icon to delete an existing rule. Note that subsequent rules move up by
one when you take this action.
