Chapter 5 Broadband
An IPv6 address using the 6to4 mode consists of an IPv4 address, the format is as the following:
2002:[a public IPv4 address in hexadecimal]::/48
For example,
A public IPv4 address is 202.156.30.41. The converted hexadecimal IP string is ca.9c.1E.29. The
IPv6 address prefix becomes 2002:ca9c:1e29::/48.
Figure 13 IPv6 6to4 Mode
IPv6
Prefix Delegation
Prefix delegation enables an IPv6 router to use the IPv6 prefix (network address) received from the
ISP (or a connected uplink router) for its LAN. The Device uses the received IPv6 prefix (for
example, 2001:db2::/48) to generate its LAN IP address. Through sending Router Advertisements
(RAs) regularly by multicast, the Device passes the IPv6 prefix information to LAN hosts. The hosts
use the prefix to generate their IPv6 addresses.

5.1.3 Before You Begin

You need to know your Internet access settings such as encapsulation and WAN IP address. Get this
information from your ISP.

5.2 The Broadband Screen

The Device must have a WAN interface to allow users to access the Internet. Use the Broadband
screen to view or modify a WAN interface.
Click Network Setting > Broadband. The following screen opens.
70
IPv4
IPv6
FMG3024-D10A / FMG3025-D10A Series User's Guide
IPv6
