Quick Start Guide
Hardware Connections
1
Connect DSL splitter using the gray
telephone cable.
2
Connect computer using the yellow Ethernet
cable.
3
Connect phone.
4
Connect power and press the
power button.
5
Check LEDs.
Internet Setup
See the User's Guide on the CD or at www.zyxel.com for more information.
EU Importer: ZyXEL Communications A/S∣Generatorvej 8D, 2730 Herlev∣http://www.zyxel.dk
1/2
US Importer: ZyXEL Communications, Inc∣1130 North Miller Street Anaheim, CA 92806-2001∣http://www.us.zyxel.com
1
5
INTERNET
Internet is ready. Go to Wireless Setup.
ON
INTERNET
Internet is not ready. Go to Internet Setup.
OFF
IP Address: 192.168.1.1
Username: admin
Password: 1234
VMG5313-B30A / VMG5313-B10A
Wireless N VDSL2 VoIP IAD with USB
DSL
LAN
PHONE1
2
3
PHONE1
ON
PHONE1
OFF
Quick Start
Copyright © 2014 ZyXEL Communications Corp. All Rights Reserved
4
VoIP registration is complete.
VoIP registration is not complete. Go to the Web
Configurator and configure VoIP settings.
