Monico CDL Gateway Installation And Operation Manual page 41

Monico PID Description
Id
195 Engine Derate Status
196 Spare Outputs (GSC+ only)
198 Relay Driver Module Relay State
Modbus Manual Remarks
Address
bit 1 = High exhaust temperature
bit 2 = High altitude (atmospheric pressure)
bit 3 = Air filter plugged
bit 4 = Engine overspeed
bit 5 = Low engine coolant temperature
bit 6 = High engine coolant temperature
bit 7 = Low engine oil pressure
bit 8 = High system voltage
bit 9 = High engine inlet air temperature
bit 10 = High engine oil temperature
bit 11 = High hydraulic oil temperature
bit 12 = No coolant flow
bit 13 = High aftercooler coolant temperature
bit 14 = High crankcase pressure
bit 15 = Fuel filter plugged
bit 16 = Oil filter plugged
bit 17 = Not used
bit 18 = Not used
bit 19 = Low coolant level
bit 20 = Alternator NOT charging
bit 21 = Low fuel level
bit 22 = High transmission oil pressure
bit 23 = Low transmission oil pressure
bit 24 = High transmission oil temperature
bit 25-32 = Not used
30207 Each of the first 24 bits represents Eng. Derate status. 0 =
Engine Derate is NOT ACTIVE
1 = Engine Derate is ACTIVE
bit 1 = High exhaust temperature
bit 2 = High altitude (atmospheric pressure)
bit 3 = Air filter plugged
bit 4 = Engine overspeed
bit 5 = Low engine coolant temperature
bit 6 = High engine coolant temperature
bit 7 = Low engine oil pressure
bit 8 = High system voltage
bit 9 = High engine inlet air temperature
bit 10 = High engine oil temperature
bit 11 = High hydraulic oil temperature
bit 12 = No coolant flow
bit 13 = High aftercooler coolant temperature
bit 14 = High crankcase pressure
bit 15 = Fuel filter plugged
bit 16 = Oil filter plugged
bit 17 = Not used
bit 18 = Not used
bit 19 = Low coolant level
bit 20 = Alternator NOT charging
bit 21 = Low fuel level
bit 22 = High transmission oil pressure
bit 23 = Low transmission oil pressure
bit 24 = High transmission oil temperature
bit 25-32 = Not used
30209 (writable) Bits 26-25 Spare Output, All other bit pairs are
undefined. 0=OFF, 1=ON, 16=Output Fault, 17=Output not
available
30213 (writable) For each group of bits: 00 = OFF/DE-
ENERGIZED; 01 = ON/ENERGIZED; 10 = Output fault; 11
= Output not available/ Don't change state.
bits 1-2 = Undefined, future use
bits 3-4 = Undefined, future use
bits 5-6 = Undefined, future use
bits 7-8 = Undefined, future use
v1.05
6.26.09
- 41 -
