Monico CDL Gateway Installation And Operation Manual page 35

Monico PID Description
Id
260 High Exhaust Port Temp Deviating Low Warning
261 High Exhaust Port Temp Deviating Low Shutdown
Modbus Manual Remarks
Address
active; 10 = Undefined; 11 = Not available, or not installed.
bits 1-2 = Underfrequency
bits 3-4 = Overfrequency
bits 5-6 = Undervoltage
bits 7-8 = Overvoltage
bits 9-10 = Generator Frequency Sensing Fault
bits 11-12 = Generator Total Overcurrent
bits 13-14 = Single Phase Overcurrent
bits 15-16 = Reverse Power
bits 17-18 = Undefined, future use
bits 19-20 = Undefined, future use
bits 21-22 = Undefined, future use
bits 23-24 = Generator Freq. Inconsistent w/Eng Speed
bits 25-26 = Undefined, future use
bits 27-28 = Undefined, future use
bits 29-30 = Undefined, future use
bits 31-32 = Undefined, future use
30260 Status indicated by bits. 0-4294967295 is Valid Range. Each
of the first 24 bits represents warning status.
0 = Warning is NOT ACTIVE
1 = Warning is ACTIVE
bit 1 = Exhaust Temperature Deviating Low
bit 2 = Exhaust Temperature Deviating High
30261 Status indicated by bits.
0 = Shutdown is NOT ACTIVE
1 = Shutdown is ACTIVE
bit 1 = Exhaust Temperature Deviating Low
bit 2 = Exhaust Temperature Deviating High
v1.05
6.26.09
- 35 -
