Diagnostic Codes
Will be supported in the near future
0=False (OFF), NonZero =True (ON) w/Fault Codes
A value of 0 indicates that the status is inactive, disabled or off.
A value of 1 indicates that the status is active, enabled or on.
0=Stop (OFF), NonZero=Start (ON)
A value of 0 indicates that the status is inactive, disabled or off.
A value of 1 indicates that the status is active, enabled or on.
Multistate
Read from Modbus register as unsigned integer. The value is composed of more than one status condition.
This is accomplished by setting the appropriate bits for each status condition. See details below:
Monico PID Description
Id
17 Engine Control Switch Position
18 Shutdown Notify Relay Status
21 Start-up Mode Status
29 Engine Prelube Status
32 Remote Throttle Override (Generator Set Only)
34 Low Idle Switch Position
63 Generator Phase A Power Factor Lead/Lag Status
64 Generator Phase B Power Factor Lead/Lag Status
65 Generator Phase C Power Factor Lead/Lag Status
66 Generator Average Power Factor Lead/Lag Status
71 EPG Circuit Breaker Status (GSP+P only)
257 Engine Coolant Pump Pressure Status
329 Hydrax Oil Pressure Switch Status
331 Emissions Feedback Mode
Multistate
Read from Modbus register as unsigned integer. The value indicates different status conditions depending on
the Caterpillar value being read. See details below:
Monico PID Description
Id
Modbus Manual Remarks
Address
30019 0=Off/reset, 2=Start, 3=Stop, 4=Auto
30020 0=Relay is OFF, 1=Relay is ON
30023 0=Starter is OFF, 1=Starter is ON, 2=Overcrank, 3=Startup
Successful, 224-255 are Fault Identifiers*
30031 Starting at 0: Prelube=OFF, ON, DISABLED,
COMPLETED. 4-255 are Fault Identifiers*
30034 0= Normal throttle setting, 1=Low idle setting, 224-255 are
Fault Identifiers*
30036 0=Switch is OFF, 1=Switch is ON, 224-255 are Fault
Identifiers*
30065 0=Current lags voltage, 1=Current leads voltage, 224-255
Fault Identifiers*
30066 0=Current lags voltage, 1=Current leads voltage, 224-255
Fault Identifiers*
30067 0=Current lags voltage, 1=Current leads voltage, 224-255
Fault Identifiers*
30068 0=Current lags voltage, 1=Current leads voltage, 224-255
Fault Identifiers*
30073 0=Breaker open, 1=Breaker closed, 228=Breaker sensor input
shorted low
30290 0=coolant pressure OK, 1=coolant pressure too high, 2=Too
Low. 0-223 is Valid Range, 224-255 are Fault Identifiers
30362 22=Open, 23=Closed. 65504-65535 are Fault Identifiers
30364 394=Combustion Time Feedback, 395=Exhaust Temperature
Feedback, 397=Calibration Feedback, 398=No Feedback,
65504-65535 are Fault Identifiers
Modbus Manual Remarks
Address
