Click "Finish" when this screen is done. There is another driver that will need to be loaded,
but it will not be found until you download the program to the CDL Gateway™. After the
initial installation or update of the CDL Gateway™ program, Microsoft will find new
hardware again and you will go through the same process again, but instead of calling it "G3
Loader", it will be called "G3 HMI".
NOTE: If your Operating System does not successfully install the drivers, you will need to
perform this function manually. Go to Start and right-click on My Computer and choose
Manage. Then click on Device Manager and look for any yellow "!" beside any USB
Devices. Right-click on the item and select Update Driver. Select Manual Installation this
time and when you are asked to specify the location of the drivers, you will choose
C:\Program Files\Monico\Monicoview\Device where the drive letter is the drive you
selected when installing the software. This should correct the problem and this issue should
not happen again. This only seems to happen the first time Windows attempts to install the
first USB driver on a new PC. If this problem occurs, it is probably because of laptop USB
port issues. Therefore, before following these instructions, disconnect the Gateway from
the USB port, disconnect the laptop from AC Power, reboot the PC, and power cycle the
Gateway.
Enabling TCP/IP Download
Any function accomplished through the USB port can also be performed over
an Ethernet Network with the exception of Firmware Upgrades. A compact
Flash card installed in the Gateway is required to Upgrade Firmware over
TCP/IP. However, you must first use the USB connections to enable "IP
DOWNLOAD" under the REMOTE UPDATE section of the Ethernet port.
Then you must go to LINK-OPTIONS and choose TCP/IP and enter the IP
address of the CDL Gateway™. From this point you can perform database
updates and port setting changes over the LAN.
Deleting Unwanted Parameters
When you expand a Block, you will see what parameters are assigned to each
register. You can delete any parameters you will not be using and this will
optimize the update rate on the CDL Link. Please keep in mind that the CDL
Gateway™ will normally update all the parameters present on an engine in
about 2-3 seconds, so for monitoring purposes there is usually no need to
optimize. However, if you highlight a register and press the delete button on
your keyboard it will remove this parameter. Make sure to save an original
copy of the program and make changes to the file using another name. After
making these changes, you must choose Link>Update to send the changes to
the CDL Gateway™. This is the case with any subsequent changes. Please note
that you will not be able to change the register locations using the User
- 15 -
