Monico CDL Gateway Installation And Operation Manual page 39

Monico PID Description
Id
60 Diagnostic Status Summary
69 General Alarm Output Status/Override (Marine Only)
99 Engine Status
116 GSC Relay Status
117 GSC Relay Control
121 GSC Alarm Status
122 GSC Shutdown Status
123 GSC Spare Fault Alarm Status
124 GSC Spare Fault Shutdown Status
146 Generator Set Control Output Status (GSC+ only)
147 Generator Set Shutdown Status - Extension #1
254 Active Warning Summary Status
Modbus Manual Remarks
Address
30062 Bits 2-1: 0=None, 1=Level 1 Warning, 2=Level2 Warning,
3=Level 3 Warning. Bit 3&4 not used. Bit 5: 0=No logged
events, 1=At least 1 logged event. Bit 6 not used. Bit7: 0=No
logged diag., 1=At least 1 logged diag. Bit8: 0=No active
diag. 1=At least 1 active diag.
30071 (This can be written to) Bit 8: 1=Override, 0=Normal. Bit 1:
0=Output is OFF, 1=Output is ON
30102 Bit 4: 1=Fuel injection disabled, 0=No injection disabled.
Bit5: 1=E-stop shutdown, 0=No E-stop shutdown. Bit 1:
1=No Engine Speed, 0=Engine Speed
30119 Organized by bit pairs where for each pair 0=Off/de-
energized, 1=On/energized, 3=Relay not installed: Bits
2,1=Air Shutoff Relay. Bits 4,3=Fuel Control Relay. Bits
6,5=Crank Terminate Relay. Bits 8,7=Starter Motor Relay.
Bits 10,9=Genset Fault Relay. Bits 12,11=Run Relay. Bits
14,13=Program Spare Relay. Bits 16,15=Electronic Governor
Relay.
30120 (only bits 16-13 are write able) Organized by bit pairs where
for each pair 0=Off/de-energized, 1=On/energized, 3=Relay
not installed, keep same state: Bits 2,1=Air Shutoff Relay.
Bits 4,3=Fuel Control Relay. Bits 6,5=Crank Terminate
Relay. Bits 8,7=Starter Motor Relay. Bits 10,9=Genset Fault
Relay. Bits 12,11=Run Relay. Bits 14,13=Program Spare
Relay. Bits 16,15=Electronic Governor Relay.
0124 Organized by bit pairs where for each pair 0=Alarm Off,
3
1=Alarm On, 3=Not Available: Bits 2,1=High Coolant Temp.
Bits 4,3=Low Coolant Temp. Bits 6,5=Low Oil Psi. Bits
8,7=Eng Control Switch not in Auto or Manual. Bits
10,9=High Oil Temp. Bits 12,11=Eng Control Alarm. Bits
14,13=Not used. Bits 16,15=Undefined.
30125 Organized by bit pairs where for each pair 0=Shutdown
Inactive, 1=Shutdown Active, 3=Not Available: Bits
2,1=Diag Code. Bits 4,3=Coolant Loss. Bits 6,5=Emg Stop.
Bits 8,7=Spare Fault. Bits 10,9=High Coolant Temp. Bits
12,11=Low Oil Psi. Bits 14,13=Overcrank. Bits
16,15=Overspeed.
30126 Organized by bit pairs where for each pair 0=Alarm Off,
1=Alarm On, 3=Not Available: Bits 2,1=Spare Fault 1. Bits
4,3=Spare Fault 2. Bits 6,5=Spare Fault 3. Bits 8,7=Spare
Fault 4. 16-9=Undefined.
30127 Organized by bit pairs where for each pair 0=Shutdown
Inactive, 1=Shutdown Active, 3=Not Available: Bits
2,1=Spare Fault 1. Bits 4,3=Spare Fault 2. Bits 6,5=Spare
Fault 3. Bits 8,7=Spare Fault 4. 16-9=Undefined.
30149 Organized by bit pairs where for each pair 0=Off/de-
energized, 1=On/energized, 2=Output Fault, 3=Output not
installed: Bits 2,1=Close Breaker Output. Bits 4,3=Kilowatt
Relay Control Output
30150 Organized by bit pairs where for each pair 0=Shutdown
Inactive, 1=Shutdown Active, 3=Not Available: Bits
13,14=Engine Control Shutdown. Bits 15,16=High Engine
Oil Temp.
30285 Bit 16=Warning Level 1, Bit 15=Warning Level 2, Bit
14=Warning Level 3 (bit value: 0=INACTIVE, 1=ACTIVE)
