will automatically start MonicoView. Select "Link" and then "Send". This will begin the
download process. During this installation, you will be asked to go through another USB
Driver installation as shown above. Then MonicoView will automatically finish loading the
upgraded program. REMEMBER, IF THIS IS THE FIRST USB DRIVER
INSTALLATION ON A PARTICULAR COMPUTER, YOU MUST USE THE
MANUAL INSTALLATION METHOD OUTLINED ABOVE.
CDL MONITOR 2.0
In build 444 and above, you will have the option to choose either CDL Monitor 1.0 or CDL
Monitor 2.0. CDL 2.0 is much faster than the old driver and automatically identifies more
engine module configurations without need for manual intervention. Also, this driver is so
fast that the NO RESPONSE DEFERRAL system used in 1.0 was no longer needed.
Therefore, data recover after loss of data link communication is only a few seconds using
CDL Monitor 2.0 instead of up to 10 minutes using CDL Monitor 1.0.
Data scan rates for all 408 potential parameters using CDL Monitor 2.0 have be measured at
.5-3 seconds. This performance is determined by network traffic and engine module
configuration, but in all cases the update rate is much improved with the new driver.
CAUTION: If you would like to convert your database to CDL Monitor 2.0, contact the
factory before attempting. In some cases, this change will invalidate any mappings
associated with the data link. However, the factory technical personnel can quickly modify
the database to avoid this problem. Simply email the .mvd file to support@monicoinc.com
and request the driver change.

Section 7: Diagnostic and Event Codes

The CDL Gateway™ now supports the Diagnostic and Event codes from the Data Link. To
activate support for Diagnostic and Event codes, double-click on the COMMUNICATIONS
tab and click on COLLECT FAULT DATA as shown in figure 7.1 below.
