Monico PID Description
Id
242 Spare Outputs (GSC+ only)
244 Relay Driver Module Relay State
258 Generator Shutdown Status (GSC+ only)
259 Generator Alarm Status (GSC+ only)
Modbus Manual Remarks
Address
bit 5 = Low engine coolant temperature
bit 6 = High engine coolant temperature
bit 7 = Low engine oil pressure
bit 8 = High system voltage
bit 9 = High engine inlet air temperature
bit 10 = High engine oil temperature
bit 11 = High hydraulic oil temperature
bit 12 = No coolant flow
bit 13 = High aftercooler coolant temperature
bit 14 = High crankcase pressure
bit 15 = Fuel filter plugged
bit 16 = Oil filter plugged
bit 17 = Not used
bit 18 = Not used
bit 19 = Low coolant level
bit 20 = Alternator NOT charging
bit 21 = Low fuel level
bit 22 = High transmission oil pressure
bit 23 = Low transmission oil pressure
bit 24 = High transmission oil temperature
bit 25-32 = Not used
30242 (writable) Bits 26-25 Spare Output, All other bit pairs are
undefined. 0=OFF, 1=ON, 16=Output Fault, 17=Output not
available
30244 (writable) For each group of bits: 00 = OFF/DE-
ENERGIZED; 01 = ON/ENERGIZED; 10 = Output fault; 11
= Output not available/ Don't change state.
bits 1-2 = Undefined, future use
bits 3-4 = Undefined, future use
bits 5-6 = Undefined, future use
bits 7-8 = Undefined, future use
bits 9-10 = Output 9
bits 11-12 = Undefined, future use
bits 13-14 = Undefined, future use
bits 15-16 = Undefined, future use
bits 17-18 = Output 5
bits 19-20 = Output 6
bits 21-22 = Output 7
bits 23-24 = Output 8
bits 25-26 = Output 1
bits 27-28 = Output 2
bits 29-30 = Output 3
bits 31-32 = Output 4
30258 For each group of bits: 00 = Shutdown inactive; 01 =
Shutdown active; 10 = Undefined; 11 = Not available, or not
installed.
bits 1-2 = Underfrequency
bits 3-4 = Overfrequency
bits 5-6 = Undervoltage
bits 7-8 = Overvoltage
bits 9-10 = Generator Frequency Sensing Fault
bits 11-12 = Generator Total Overcurrent
bits 13-14 = Single Phase Overcurrent
bits 15-16 = Reverse Power
bits 17-18 = Undefined, future use
bits 19-20 = Undefined, future use
bits 21-22 = Undefined, future use
bits 23-24 = Generator Freq. Inconsistent w/Eng Speed
bits 25-26 = Undefined, future use
bits 27-28 = Undefined, future use
bits 29-30 = Undefined, future use
bits 31-32 = Undefined, future use
30259 For each group of bits: 00 = Alarm inactive; 01 = Alarm
