Monico CDL Gateway Installation And Operation Manual page 33

Monico PID Description
Id
239 Warning Status
240 Shutdown Status
241 Engine Derate Status
Modbus Manual Remarks
Address
30239 Each of the first 24 bits represents warning status.
0 = Warning is NOT ACTIVE
1 = Warning is ACTIVE
bit 1 = High exhaust temperature
bit 2 = High altitude (atmospheric pressure)
bit 3 = Air filter plugged
bit 4 = Engine overspeed
bit 5 = Low engine coolant temperature
bit 6 = High engine coolant temperature
bit 7 = Low engine oil pressure
bit 8 = High system voltage
bit 9 = High engine inlet air temperature
bit 10 = High engine oil temperature
bit 11 = High hydraulic oil temperature
bit 12 = No coolant flow
bit 13 = High aftercooler coolant temperature
bit 14 = High crankcase pressure
bit 15 = Fuel filter plugged
bit 16 = Oil filter plugged
bit 17 = Not used
bit 18 = Not used
bit 19 = Low coolant level
bit 20 = Alternator NOT charging
bit 21 = Low fuel level
bit 22 = High transmission oil pressure
bit 23 = Low transmission oil pressure
bit 24 = High transmission oil temperature
bit 25-32 = Not used
30240 Each of the first 24 bits represents Shutdown status.
0 = Engine Shutdown is NOT ACTIVE
1 = Engine Shutdown is ACTIVE
bit 1 = High exhaust temperature
bit 2 = High altitude (atmospheric pressure)
bit 3 = Air filter plugged
bit 4 = Engine overspeed
bit 5 = Low engine coolant temperature
bit 6 = High engine coolant temperature
bit 7 = Low engine oil pressure
bit 8 = High system voltage
bit 9 = High engine inlet air temperature
bit 10 = High engine oil temperature
bit 11 = High hydraulic oil temperature
bit 12 = No coolant flow
bit 13 = High aftercooler coolant temperature
bit 14 = High crankcase pressure
bit 15 = Fuel filter plugged
bit 16 = Oil filter plugged
bit 17 = Not used
bit 18 = Not used
bit 19 = Low coolant level
bit 20 = Alternator NOT charging
bit 21 = Low fuel level
bit 22 = High transmission oil pressure
bit 23 = Low transmission oil pressure
bit 24 = High transmission oil temperature
bit 25-32 = Not used
30241 Each of the first 24 bits represents Eng. Derate status. 0 =
Engine Derate is NOT ACTIVE
1 = Engine Derate is ACTIVE
bit 1 = High exhaust temperature
bit 2 = High altitude (atmospheric pressure)
bit 3 = Air filter plugged
bit 4 = Engine overspeed
v1.05
6.26.09
- 33 -
