Monico CDL Gateway Installation And Operation Manual page 30

59 Generator Phase A Power Factor Lead/Lag Status
60 Generator Phase B Power Factor Lead/Lag Status
61 Generator Phase C Power Factor Lead/Lag Status
62 Generator Average Power Factor Lead/Lag Status
67 EPG Circuit Breaker Status (GSP+P only)
151 Engine Coolant Pump Pressure Status
200 Hydrax Oil Pressure Switch Status
202 Emissions Feedback Mode
Multistate
Read from modbus register as unsigned integer. The value indicates different status conditions depending on
the value being read. See details below:
Monico PID Description
Id
22 Generator Phase Select
25 Generator AC Voltage Full Scale and External PT
Setpoint
26 Generator AC Current Full Scale Setpoint (Read)
31 ECM in Control (Marine Only)
57 Generator AC Voltage Full Scale Transformer Setpoint
58 Generator AC Current Full Scale Setpoint
68 Remote Generator Synchronizer Control (GSP+P only)
69 Remote Synchronization Control Readiness (GSP+P
only)
70 Generator Synchronizer Control Status (GSP+P only)
201 Normal Stop Input Status
30059 0=Current lags voltage, 1=Current leads voltage, 224-255
Fault Identifiers*
30060 0=Current lags voltage, 1=Current leads voltage, 224-255
Fault Identifiers*
30061 0=Current lags voltage, 1=Current leads voltage, 224-255
Fault Identifiers*
30062 0=Current lags voltage, 1=Current leads voltage, 224-255
Fault Identifiers*
30067 0=Breaker open, 1=Breaker closed, 228=Breaker sensor input
shorted low
30151 0=coolant pressure OK, 1=coolant pressure too high, 2=Too
Low. 0-223 is Valid Range, 224-255 are Fault Identifiers
30200 22=Open, 23=Closed. 65504-65535 are Fault Identifiers
30202 394=Combustion Time Feedback, 395=Exhaust Temperature
Feedback, 397=Calibration Feedback, 398=No Feedback,
65504-65535 are Fault Identifiers
Modbus Manual Remarks
Address
30022 0=Phase A-B Volts A current, 1=Phase B-C Volts B current,
2=Phase C-A Volts C current
30025 0=700v, 1=150v, 2=300, 3=500, 4=600, 5=750, 6=3k,
7=4.5k, 8=5.25k, 9=9k, 10=15k, 11=18k, 12=30k
30026 starting at 0:
75,100,150,200,300,400,600,800,1k,1.2k,1.5k,2k,2.5k,3k,4k
Amps
30031 0=Primary ECM is controlling, 1=Backup ECM is controlling
30057 0=700v, 1=150v, 2=300, 3=500, 4=600, 5=750, 6=3k,
7=4.5k, 8=5.25k, 9=9k, 10=15k, 11=18k, 12=30k
30058 starting at 0:
75,100,150,200,300,400,600,800,1k,1.2k,1.5k,2k,2.5k,3k,4k
Amps
30068 (This can be written to) 0=Off, 1=Remote synchronization
test, 2=Automatic synchronization
30069 0=Not installed, 1=ready for remote command,
2=Synchronizing switch not in auto, 3=Engine control switch
not in auto, 4 Engine was not started remotely, 5 Engine not
running
30070 Starting at 0: Not installed, Inactive, Semiautomatic
paralleling, Permissive paralleling, Remote synchronization
testing, Synchronizing, Synchronization system alarm or
diag., Remote synchronization testing passed, Dead bus time
delay, Closing to dead bus.
30201 113=Run, 174=Stop
v1.05
6.26.09
- 30 -
