Monico CDL Gateway Installation And Operation Manual page 38

Monico PID Description
Id
24 Generator Phase Select
27 Generator AC Voltage Full Scale and External PT
Setpoint
28 Generator AC Current Full Scale Setpoint (Read)
33 ECM in Control (Marine Only)
61 Generator AC Voltage Full Scale Transformer Setpoint
62 Generator AC Current Full Scale Setpoint
72 Remote Generator Synchronizer Control (GSP+P only)
73 Remote Synchronization Control Readiness (GSP+P
only)
74 Generator Synchronizer Control Status (GSP+P only)
330 Normal Stop Input Status
Multiple Status Bits
Read from Modbus register as unsigned integer. The value is composed of more than one status condition.
This is accomplished by setting the appropriate bits for each status condition. See details below:
Monico PID Description
Id
6 Oxygen Sensor Status
8 Ignition Timing Calibration
42 G3600 Engine Status
43 Engine Operation
48 Auxiliary Status
55 EIS Special Test Status
Modbus Manual Remarks
Address
30026 0=Phase A-B Volts A current, 1=Phase B-C Volts B current,
2=Phase C-A Volts C current
30029 0=700v, 1=150v, 2=300, 3=500, 4=600, 5=750, 6=3k,
7=4.5k, 8=5.25k, 9=9k, 10=15k, 11=18k, 12=30k
30030 starting at 0:
75,100,150,200,300,400,600,800,1k,1.2k,1.5k,2k,2.5k,3k,4k
Amps
30035 0=Primary ECM is controlling, 1=Backup ECM is controlling
30063 0=700v, 1=150v, 2=300, 3=500, 4=600, 5=750, 6=3k,
7=4.5k, 8=5.25k, 9=9k, 10=15k, 11=18k, 12=30k
30064 starting at 0:
75,100,150,200,300,400,600,800,1k,1.2k,1.5k,2k,2.5k,3k,4k
Amps
30074 (This can be written to) 0=Off, 1=Remote synchronization
test, 2=Automatic synchronization
30076 0=Not installed, 1=ready for remote command,
2=Synchronizing switch not in auto, 3=Engine control switch
not in auto, 4 Engine was not started remotely, 5 Engine not
running
30077 Starting at 0: Not installed, Inactive, Semiautomatic
paralleling, Permissive paralleling, Remote synchronization
testing, Synchronizing, Synchronization system alarm or
diag., Remote synchronization testing passed, Dead bus time
delay, Closing to dead bus.
30363 113=Run, 174=Stop
Modbus Manual Remarks
Address
30006 Bits set to 1 indicate Status: 8=start cal. 7= cal in progress,
6=sensor on, 5= command sensor on
30008 Bits set to 1 indicate Status: 8=cal good else cal bad, 7=
enable cal else disable cal
30044 Bit8: 0=idle, 1=rated. Bit7: 0=off grid, 1=on grid. Bit6-5:
00=running, 01=coasting, 10=shutdown, 11=not used
30045 Bit8: 0=genset, 1=industrial. Bit6: 0=isochronous governor,
1=droop governor
30050 Mode Control Switch Bit8-7: 11=start, 10=auto, 01=stop,
00=off/reset. E-Stop Bit 6: 1=stop, 0=run. Driven
Equipment Bit5: 1=Ready, 0=Not Ready. Prelube Slave
Relay Bit 4: 1=ON, 2=OFF. Prelube Relay Bit3: 1=ON,
2=OFF. Prelube Switch Bit2: 1=Not Ready, 0=Ready.
Initiate Contact Bit1: 1=Stop, 0=Run.
30057 Inactive (Tests should only be done on-site) bit 8: 1=Enable
special test, 0=disable. Bit7: 0=proceed to test B. Bit5-1
0=test passed. Non zero=# of tests failed
v1.05
6.26.09
- 38 -
