Monico CDL Gateway Installation And Operation Manual page 31

Multiple Status Bits
Read from modbus register as unsigned integer. The value is composed of more than one status condition. This
is accomplished by setting the appropriate bits for each status condition. See details below:
Monico PID Description
Id
6 Oxygen Sensor Status
8 Ignition Timing Calibration
40 G3600 Engine Status
41 Engine Operation
46 Auxiliary Status
52 EIS Special Test Status
56 Diagnostic Status Summary
65 General Alarm Output Status/Override (Marine Only)
77 Engine Status
90 GSC Relay Status
91 GSC Relay Control
93 GSC Alarm Status
Modbus Manual Remarks
Address
30006 Bits set to 1 indicate Status: 8=start cal. 7= cal in progress,
6=sensor on, 5= command sensor on
30008 Bits set to 1 indicate Status: 8=cal good else cal bad, 7=
enable cal else disable cal
30040 Bit8: 0=idle, 1=rated. Bit7: 0=off grid, 1=on grid. Bit6-5:
00=running, 01=coasting, 10=shutdown, 11=not used
30041 Bit8: 0=genset, 1=industrial. Bit6: 0=isochronous govenor,
1=droop govenor
30046 Mode Control Switch Bit8-7: 11=start, 10=auto, 01=stop,
00=off/reset. E-Stop Bit6: 1=stop, 0=run. Driven
Equipment Bit5: 1=Ready, 0=Not Ready. Prelube Slave
Relay Bit4: 1=ON, 2=OFF. Prelube Relay Bit3: 1=ON,
2=OFF. Prelube Switch Bit2: 1=Not Ready, 0=Ready.
Initiate Contact Bit1: 1=Stop, 0=Run.
30052 Inactive (Tests should only be done on-site) bit 8: 1=Enable
special test, 0=disable. Bit7: 0=proceed to test B. Bit5-1
0=test passed. Non zero=# of tests failed
30056 Bits 2-1: 0=None, 1=Level 1 Warning, 2=Level2 Warning,
3=Level 3 Warning. Bit 3&4 not used. Bit 5: 0=No logged
events, 1=At least 1 logged event. Bit 6 not used. Bit7: 0=No
logged diag., 1=At least 1 logged diag. Bit8: 0=No active
diag. 1=At least 1 active diag.
30065 (This can be written to) Bit 8: 1=Override, 0=Normal. Bit 1:
0=Output is OFF, 1=Output is ON
30077 Bit 4: 1=Fuel injection disabled, 0=No injection disabled.
Bit5: 1=E-stop shutdown, 0=No E-stop shutdown. Bit 1:
1=No Engine Speed, 0=Engine Speed
30090 Organized by bit pairs where for each pair 0=Off/de-
energized, 1=On/energized, 3=Relay not installed: Bits 2,
1=Air Shutoff Relay. Bits 4,3=Fuel Control Relay. Bits
6,5=Crank Terminate Relay. Bits 8,7=Starter Motor Relay.
Bits 10,9=Genset Fault Relay. Bits 12,11=Run Relay. Bits
14,13=Program Spare Relay. Bits 16,15=Electronic Govenor
Relay.
30091 (only bits 16-13 are write able) Organized by bit pairs where
for each pair 0=Off/de-energized, 1=On/energized, 3=Relay
not installed, keep same state: Bits 2,1=Air Shutoff Relay.
Bits 4,3=Fuel Control Relay. Bits 6,5=Crank Terminate
Relay. Bits 8,7=Starter Motor Relay. Bits 10,9=Genset Fault
Relay. Bits 12,11=Run Relay. Bits 14,13=Program Spare
Relay. Bits 16,15=Electronic Govenor Relay.
3 0093 Organized by bit pairs where for each pair 0=Alarm Off,
1=Alarm On, 3=Not Available: Bits 2,1=High Coolant Temp.
Bits 4,3=Low Coolant Temp. Bits 6,5=Low Oil Psi. Bits
8,7=Eng Control Switch not in Auto or Manual. Bits
10,9=High Oil Temp. Bits 12,11=Eng Control Alarm. Bits
14,13=Not used. Bits 16,15=Undefined.
