Table 3: Connection Scheme (for the example in Figure 3)

This connector:
RELAY2
RELAY1
RS-485 Terminal Block Connector
RS-232 (TX1, RX1) Terminal Block Connector
2
IR OUT1 PIN
2
IR OUT2 PIN
Ethernet
A laptop is connected to the projector
Figure 4 shows the RC-8IR built into a podium that is located in a lecture
auditorium. An overhead projector and screen, speakers, lights; and a cabinet
with a VCR, a DVD and an amplifier inside, are all controlled via the
RC-8IR. The presenter's laptop is located on the podium, next to where the
RC-8IR is mounted. It is also controlled by the RC-8IR and is used for
presentations, slide shows and so on.

Figure 4: Example of a Typical RC-8IR Setup in the Lecture Auditorium

1 The second RS-232 port can be used to control another A/V unit or an LCD
2 Connected via the IR emitter cable. IR OUT1 and IR OUT2 can each be connected to identical machines and still be
controlled separately
3 Each IR connector can control two different machines via a dual emitter cable. For example, a DVD player and a
document camera could be connected to the same IR connector (not shown in Figure 3)
Introduction
The lights
The screen
A power amplifier (and speakers)
1
A projector
A DVD player
A video player
The RC-8IR via a remote control PC
Controls:
3
VCR
DVD
Amplifier
7
