5.3 Using the Macro Buttons

Pressing any button initiates a macro sequence
blinks (as programmed by the system integrator).
If during the macro sequence the button blinks faster than usual
that a malfunction has been detected
If you want to stop a macro sequence, press and hold that button for 5
seconds. The sequence will come to an end. You can resume operation by
pressing any of the buttons
commands from the beginning.

5.4 Locking the Front Panel

The front panel can be locked to avoid unintended tampering with the buttons.
To lock the panel press and hold buttons 7 and 8 simultaneously for about 2
seconds (as illustrated in Figure 7).
All the buttons blink momentarily and the panel is locked.
When pressing a button at this stage, all the buttons blink twice.
To unlock the panel buttons, press the same buttons once again. All the
buttons blink momentarily and unlock. You can now use the buttons as usual.

5.5 Turning the Light of the Backlit Buttons On and Off

When the room is darkened, the buttons can be illuminated for convenience.
To turn on the backlight press buttons 5 and 6 simultaneously (as illustrated
in Figure 7).
To turn off the backlight, press the respective buttons once again.
1 The macro sequence can be carried out instantly or can take a while, depending on the delay times included in the sequence
2 Six times per second, as compared with twice per second during normal operation
3 For example, a faulty DVD player
4 In this example, press the HELP DESK button
5 Including the button you kept pressed to stop the macro sequence
10
Using Your Universal Room Controller
To solve the problem, summon technical help
5
. The unit will carry out the macro sequence
1
, during which the button
3
and the RC-8IR exits the macro sequence.
