Page 1: User Manual
Kramer Electronics, Ltd. USER MANUAL Models: RC-7B, Media / Room Controller RC-7BE, Media / Room Controller... -
Page 2: Table Of Contents
Figures Figure 1: RC-7B Front Panel Figure 2: RC-7BE Front Panel Figure 3: Side Panel of the RC-7B and RC-7BE (Enlarged View) Figure 4: Side Panel of the RC-7B and RC-7BE Figure 5: RC-7BE (Front Perspective) Configuration Figure 6: RC-7BE (Rear Perspective) Configuration... -
Page 3: Introduction
IR learner 4 By authorized Kramer technical personnel or by an external system integrator (refer to the separate online guide) 5 That provides information about how to set up the system. This online guide may well be updated on a regular basis. For... -
Page 4: Getting Started
A/V equipment in any multimedia room, especially the control of a projector or other display device, via RS-232 and/or IR emitter cable. The RC-7B / RC-7BE is 12V DC fed. The RC-7B is a one-gang wall plate. The RC-7BE is two-gang wall plate intended for the European market. - Page 5 (often associated with low quality cables) Avoid interference from neighboring electrical appliances and position the RC-7B / RC-7BE away from moisture, excessive sunlight and dust Caution – No operator-serviceable parts inside unit.
-
Page 6: Your Rc-7B / Rc-7Be
1 These screws should not be removed during or after mounting 2 Via the front panel, without having to remove the RC-7B from its mounting 3 Letting you configure the RC-7B directly from the remote transmitter without the need for software KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 7: Defining The Rc-7Be Front Panel
Your RC-7B / RC-7BE 4.2 Defining the RC-7BE Front Panel Figure 2 and Table 2 define the RC-7BE front panel: Figure 2: RC-7BE Front Panel Table 2: RC-7BE Front Panel Feature Function Mounting holes (4) For fastening the controller in place... -
Page 8: Defining The Rc-7B / Rc-7Be Side Panel
Your RC-7B / RC-7BE 4.3 Defining the RC-7B / RC-7BE Side Panel Figure 3 illustrates an enlarged view of the side panel of the RC-7B and RC-7BE: Figure 3: Side Panel of the RC-7B and RC-7BE (Enlarged View) Figure 4 defines the side panel of the RC-7B and RC-7BE. For an... -
Page 9: Figure 4: Side Panel Of The Rc-7B And Rc-7Be
) . % , ! & ' 234, !56 & % '* !+ ', , ) - '() & '( ) 8 # 3 7 ( !" # % 0 1 Figure 4: Side Panel of the RC-7B and RC-7BE... -
Page 10: Using Your Media / Room Controller
RC-7BE configuration. It connects to the projector via IR or RS-232: Figure 5: RC-7BE (Front Perspective) Configuration 1 From this section on, all the information is relevant to both the RC-7B and the RC-7BE, unless noted otherwise KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 11: Figure 6: Rc-7Be (Rear Perspective) Configuration
Using Your Media / Room Controller The example in Figure 6 shows a rear view perspective of a typical RC-7BE configuration. It connects to the projector via RS-232. The connected sources—the DVD and VCR—connect to the dedicated video and audio inputs of the projector: Figure 6: RC-7BE (Rear Perspective) Configuration... -
Page 12: Figure 7: Example Of A Typical Setup In The Lecture Auditorium
RC-7BE. The presenter’s laptop is located on the podium, next to the RC-7BE. It is also controlled by the RC-7BE and is used for presentations and slide shows. Figure 7: Example of a Typical Setup in the Lecture Auditorium KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 13: Operating The Rc-7B / Rc-7Be
Using Your Media / Room Controller 5.1 Operating the RC-7B / RC-7BE In the example defined in Table 3, the RC-7B buttons are labeled ON, OFF, VOL UP, VOL DOWN on the control buttons and PC, DVD and VCR on... -
Page 14: Using The Macro Buttons
5.3 An Example of Operating the RC-7B / RC-7BE Figure 8 shows an example of how to operate the RC-7B / RC-7BE: Select the DVD input on the projector and play the DVD. Select the PC input on the projector and resume the slide show. -
Page 15: Flash Memory Upgrade
Applet dat file, to a folder (for example, C:\Program Files\KFR Upgrade). 3. Install the KFR-Programmer Application. Connecting the PC to the RS-232 Port Before installing the latest Kramer Ethernet firmware version on the RC- B, do the following: to the CONFIG port on the RC-7B 1. -
Page 16: Technical Specifications
15.1cm x 4.4cm x 8.6cm (5.94" x 1.75" x 3.39", W, D, H) WEIGHT: 0.3kg (0.67lbs.) approx ACCESSORIES: Power supply, Windows -based Kramer control and configuration software OPTIONS: Dual IR emitter cable , single IR emitter cable , IR extension cable, CONFIG. - Page 17 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
- Page 18 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
