Kramer RC-7RL User Manual

Media / room controller
Hide thumbs Also See for RC-7RL:

Advertisement

Quick Links

im Vertrieb von
www.camboard.de
CAMBOARD Electronics
Kramer Electronics, Ltd.
USER MANUAL
Models:
RC-7RL,
Media / Room Controller
RC-7RLE,
Media / Room Controller
Tel. 07131 911201
Fax 07131 911203
ce-info@camboard.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RC-7RL and is the answer not in the manual?

Questions and answers

Summary of Contents for Kramer RC-7RL

  • Page 1 Vertrieb von CAMBOARD Electronics Kramer Electronics, Ltd. USER MANUAL Models: RC-7RL, Media / Room Controller RC-7RLE, Media / Room Controller www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 2: Table Of Contents

    Figures Figure 1: RC-7RL Front Panel Figure 2: RC-7RLE Front Panel Figure 3: Side Panel of the RC-7RL and RC-7RLE (Enlarged View) Figure 4: Side Panel of the RC-7RL and RC-7RLE Figure 5: RC-7RLE (Front Perspective) Figure 6: RC-7RLE (Rear Perspective)
  • Page 3: Introduction

    IR learner 4 By authorized Kramer technical personnel or by an external system integrator (refer to the separate online guide) 5 That provides information about how to set up the system. This online guide may well be updated on a regular basis. For the latest online guide, go to http://www.kramerelectronics.com...
  • Page 4: Getting Started

    A/V equipment in any multimedia room, especially the control of a projector or other display device, via RS-232 and/or IR emitter cable. The RC-7RL / RC-7RLE is 12V DC fed. The RC-7RL is a one-gang wall plate. The RC-7RLE is two-gang wall plate intended for the European market.
  • Page 5 (often associated with low quality cables) Avoid interference from neighboring electrical appliances and position the RC-7RL / RC-7RLE away from moisture, excessive sunlight and dust Caution – No operator-serviceable parts inside unit.
  • Page 6: Your Rc-7Rl / Rc-7Rle

    1 These screws should not be removed during or after mounting 2 Via the front panel, without having to remove the RC-7RL from its mounting 3 Letting you configure the RC-7RL directly from the remote transmitter without the need for software www.camboard.de Tel.
  • Page 7: Defining The Rc-7Rle Front Panel

    Vertrieb von CAMBOARD Electronics Your RC-7RL / RC-7RLE 4.2 Defining the RC-7RLE Front Panel Figure 2 and Table 2 define the RC-7RLE front panel: Figure 2: RC-7RLE Front Panel Table 2: RC-7RLE Front Panel Feature Function Mounting holes (4)
  • Page 8: Defining The Rc-7Rl / Rc-7Rle Side Panel

    CAMBOARD Electronics Your RC-7RL / RC-7RLE 4.3 Defining the RC-7RL / RC-7RLE Side Panel Figure 3 illustrates an enlarged view of the side panel of the RC-7RL and RC-7RLE: Figure 3: Side Panel of the RC-7RL and RC-7RLE (Enlarged View) Figure 4 defines the side panel of the RC-7RL and RC-7RLE.
  • Page 9: Figure 4: Side Panel Of The Rc-7Rl And Rc-7Rle

    *(4 1 ( # $ % 3 " 4 1 ( 1 ( ! " # $ % 3 " 4 $ % % / Figure 4: Side Panel of the RC-7RL and RC-7RLE www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 10: Using Your Media / Room Controller

    RC-7RLE configuration. It connects to the projector via IR or RS-232: Figure 5: RC-7RLE (Front Perspective) 1 From this section on, all the information is relevant to both the RC-7RLE and the RC-7RL, unless noted otherwise www.camboard.de Tel. 07131 911201 ce-info@camboard.de...
  • Page 11: Figure 6: Rc-7Rle (Rear Perspective)

    im Vertrieb von CAMBOARD Electronics Using Your Media / Room Controller The example in Figure 6 shows a rear view perspective of a typical RC-7RLE configuration. It connects to the projector via RS-232, and the relays connect to the screen and lighting system. Each source—the PC, DVD and VCR—connects to the dedicated video and audio inputs of the projector: Figure 6: RC-7RLE (Rear Perspective) www.camboard.de...
  • Page 12: Figure 7: Example Of A Typical Setup In The Lecture Auditorium

    RC-7RLE. It is also controlled by the RC-7RLE and is used for presentations and slide shows. Figure 7: Example of a Typical Setup in the Lecture Auditorium www.camboard.de Tel. 07131 911201 ce-info@camboard.de KRAMER: SIMPLE CREATIVE TECHNOLOGY Fax 07131 911203...
  • Page 13: Operating The Rc-7Rl / Rc-7Rle

    (as programmed by the system integrator). If during the macro sequence the button blinks faster than usual , this indicates and the RC-7RL / RC-7RLE exits the that a malfunction has been detected macro sequence. To solve the problem, summon technical help If you want to stop a macro sequence, press and hold that button for 5 seconds.
  • Page 14: An Example Of Operating The Rc-7Rl / Rc-7Rle

    Flash Memory Upgrade 5.3 An Example of Operating the RC-7RL / RC-7RLE Figure 8 shows an example of how to operate the RC-7RL / RC-7RLE: Select the DVD input on the projector and play the DVD. Select the PC input on the projector and resume the slide show.
  • Page 15: Downloading From The Internet

    Applet dat file, to a folder (for example, C:\Program Files\KFR Upgrade). 3. Install the KFR-Programmer Application. Connecting the PC to the RS-232 Port Before installing the latest Kramer Ethernet firmware version on the RC- RL, do the following: to the CONFIG port on the RC-7RL 1.
  • Page 16: Technical Specifications

    RC-7RLE: 15.1cm x 4.4cm x 8.6cm (5.94" x 1.75" x 3.39", W, D, H) WEIGHT: 0.3kg (0.67lbs) approx ACCESSORIES: Power supply, Windows -based Kramer control and configuration software OPTIONS: Dual IR emitter cable, single IR emitter cable, IR extension cable, CONFIG. cable...
  • Page 17 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
  • Page 18 Vertrieb von CAMBOARD Electronics For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
