Icom IC-706MKIIG Instruction Manual page 58

7
SET MODE
When an optional UT-102
is installed, the synthesizer can be set to read out the
frequency/mode only, or both the frequency/mode
and S-meter level.
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-706MKIIG's address is 4EH.
When 2 or more IC-706MKIIG's are connected to an
optional CT-17
main dial to select a different address for each IC-
706MKIIG in the range 01H to 7FH.
This item sets the data transfer rate. When "Auto" is
selected, the baud rate is automatically set according
to the connected controller or remote controller.
Transceive operation is possible with the IC-
706MKIIG connected to other Icom HF transceivers
or receivers. When "on" is selected, changing the
frequency, operating mode, etc. on the IC-706MKIIG
automatically changes those of connected trans-
ceivers (or receivers) and vice versa.
When connecting the IC-706MKIIG to the IC-735 for
transceive operation, you must change the operat-
ing frequency data length to 4 bytes.
• This item be set to "on" only when operating trans-
MUST
ceiver with the IC-735.
55
SPEECH SYNTHESIZER UNIT
- , rotate the
CI V LEVEL CONVERTER
Voice synthesizer reads out
both the frequency/mode
and S-meter level (default).
Address set to 58H
(default).
Auto baud rate
(default)
Transceive ON
(default)
Frequency data set to
5 bytes (default).
Voice synthesizer reads out
the frequency/mode only.
Address set to 7FH.
19200 bps
Transceive OFF
Frequency data set to
4 bytes.
