Icom IC-706MKIIG Instruction Manual page 57

The optional AT-180
ANTENNA TUNER
ic start capability which starts tuning if the SWR is
higher than 1.5–3.
When "oFF" is selected, the tuner remains OFF
even when the SWR is poor (1.5–3).
When "on" is selected, automatic tune starts even
when the tuner is turned OFF.
When an optional AH-4
ANTENNA TUNER
ed, tuning can be started automatically at the
moment the PTT is pushed.
This is used to change the communications speed
packet operation. The data socket can be set to
1200 or 9600 baud.
"on": VSEND is for 144/430 MHz; HSEND is for
the HF/50 MHz
"U only": VSEND is for 430 MHz; HSEND is for
HF/50/144 MHz
"oFF": VSEND is not used; HSEND is for all bands.
When the optional UT-102
installed, you can select between English and
Japanese as the language.
When the optional UT-102
installed, you can select between faster or slower
synthesizer output.
has an automat-
is connect-
is
VOICE SYNTHESIZER UNIT
is
VOICE SYNTHESIZER UNIT
Auto tune function OFF
(default).
Even when "on" is selected, automatic tune
does not start for the 50 MHz band.
Tuning starts only when
[TUNER] is pushed (default).
Default is 9600 baud.
The default is VSEND is for the 144/430 MHz band;
HSEND is for the HF/50 MHz band.
Voice synthesizer functions
in English (default).
Voice synthesizer output
is faster (default).
7
SET MODE
Auto tune function ON.
Tuning starts when pushing [PTT]
on a new frequency.
Voice synthesizer functions
in Japanese.
Voice synthesizer output
is slower.
54
