IMB203 LGA775 ATX Motherboard User's Manual
1.1

Specifications

CPU
®
™
Intel Core
System Chipset
®
Intel Q45 and ICH10/R/DO (co-layout)
CPU Socket
LGA775 Socket
Front-Side Bus
800/1066/1333 MHz
BIOS
AMI BIOS via SPI interface with socket
System Memory
Four 240-pin DDR3 DIMM sockets
Maximum up to 16GB DDR3 memory
Supports DDR3 800/1066 memory
L2 Cache
Integrated in CPU
Onboard Multi-I/O
SPP/EPP/ECP supported; with D-Sub connector on the rear
I/O
Serial Ports:
9-pin D-Sub connector on the rear I/O and supports RS-
COM 1
232/422/485 with jumper selectable, RS-485 with auto-flow control
COM 2 2*5-pin 2.54 pitch box-header; supports RS-232
COM 3 2*5-pin 2.54 pitch box-header; supports RS-232
COM 4 2*5-pin 2.54 pitch box-header; supports RS-232
2
™
2 Quad / Core 2 Duo processors
Introduction
