IMB203 LGA775 ATX Motherboard User's Manual
HARDWARE INSTALLATION
Before installing the processor, please access Intel
detailed information http://www.intel.com .
3.1
Installing the Processor
The LGA775 processor socket comes with a cover to protect the processor.
Please install the processor into the CPU socket step by step as below:
Hold the hook (A) of the lever and push it down.
Pull the lever (B) aside to unlock the cover.
Hardware Installation
CHAPTER 3
®
website for more
23
