IMB203 LGA775 ATX Motherboard User's Manual
USB Interface
Tweleve USB ports (four on I/O bracket, six ports by 2x5-pin
2.54 pin-header, two ports for 1 USB DoM support with 2x5
2.54 pitch box-header)
VGA Controller
Chipset -- Intel
supports 3D, 2D, video capabilities, DX10 and OpenGL 2.1
Memory Size -- Intel
memory for frame buffer option as 32/48/64/128/256MB,
and 96 MB (0 + 96), 160 MB (64 + 96), 224 MB (128 + 96),
352 MB (256 + 96).
Resolution -- Analog output -- the analog port utilizes an
integrated 350MHz RAMDAC that can directly drive a
standard progressive scan analog monitor up to a resolution
of 2048x1536 pixels with 32-bit color at 75 Hz
Analog Output Interface -- CRT from DAC output via 15-pin
D-Sub connector on the edge
Ethernet
®
LAN1 – Intel
supports 10/100/1000 Base-T Gigabit Ethernet, RJ-45
connector on the edge; with AMT Gen 5 supported; with 5-
pin 2.0 pitch wafer for LED
®
LAN2 -- Intel
supports 10/100/1000 Base-T Gigabit Ethernet, RJ-45
connector on the edge; with 5-pin 2.0 pitch wafer for LED
Serial ATA
Six Serial ATA-II ports (3Gb/s performance) and SATARAID
0/1/5/10 by ICH10-DO
Audio
HD Audio codec Realtek ALC888 for Line/speaker-out &
MIC-in on the rear I/O double deck connector; with LM1877
audio amplifier
Expansion Slot
1 PCIe (x16) , 4 PCI Slot (32bit/33MHZ)
1 PCIe (x4), 1 PCIe (x1)(Note 1)
Introduction
®
integrated Graphics Gen5 on Intel
®
DVMT supported; preallocated
82567LM PHY, connected to PCIe x1 port#6;
82574L NIC, connected to PCIe x1 port#5;
®
Q45
3
