Section 3. Installation Instructions Model APURE700 and APURE1400
3.1 Materials and Tools
NOTE Salt not included. See pages 17 - 20.
Installation Materials Furnished
Electrolytic Cell with 2"-2.5" Universal Unions
Port Plug with 16 ft (4.88 m) Sensor and O-Ring
Universal Union Nut
16 ft (4.88 m) DC Power Cord
Power Supply/Control Center
Anchors and Screws
Owner's Manual - Warranty Information
3.2 Plumbing Conﬁ gurations
When using electrical products, basic precautions should always be followed, including the following:
DANGER: RISK OF ELECTRIC SHOCK WHICH CAN RESULT IN SERIOUS INJURY OR DEATH.
Before attempting installation or service, ensure that all power to the device is disconnected/turned
off at the circuit breaker. Connect only to a circuit protected by a ground-fault circuit-interrupter
Grounding is required. The unit should be installed by a qualiﬁ ed service representative and
should be properly grounded. (See Earth Bonding, page 11).
Install to permit access for servicing.
Read Cautions and Important Instructions on page 4. Before attempting any electrical wiring, be
sure to read and follow Safety Instructions. Wiring should only be attempted by a qualiﬁ ed
Tools Needed for Installation
Phillips & Flathead Screwdrivers
Voltmeter to determine line voltage of AC wiring to power supply
Electric Drill Motor and 1/4 " masonry drill bit for mounting power supply on
block or stucco wall
approved All Purpose Cleaner Primer
approved All Purpose Cement (such as Weld-On 794, 793)
