FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and
qualified in pool equipment by the jurisdiction in which the product will be installed where such state
or local requirements exist. The maintainer must be a professional with sufficient experience in pool
equipment installation and maintenance so that all of the instructions in this manual can be followed
exactly. Before installing this product, read and follow all warning notices and instructions that accompany
this product. Failure to follow warning notices and instructions may result in property damage, personal
injury, or death. Improper installation and/or operation will void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which can
cause serious injury, property damage, or death.
ATTENTION INSTALLER - This manual contains important information about the
installation, operation and safe use of this product. This information should be given to
the owner/operator of this equipment.
Diatomaceous Earth Pool Filters
WARNING
INSTALLATION AND
OPERATION MANUAL
Jandy
Pro Series
®
ENGLISH
DEV
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jandy Pro Series
Summary of Contents for Jandy Pro Series
- Page 1 INSTALLATION AND OPERATION MANUAL ENGLISH Jandy Pro Series ® Diatomaceous Earth Pool Filters WARNING FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local requirements exist.
-
Page 3: Table Of Contents
Clamp Installation, DEV Series ......8 Jandy DEV Filter Parts List ......15 Section 4. Start-Up and Operation ....9 Exploded View of Jandy DEV Filter ....15 Preparing Diatomaceous Earth ......9 Section 10. Head Loss Curves ......16 Coating the Filter Grids ........ -
Page 4: Section 1. Safety Information
• Water temperature for test must NOT EXCEED 100°F (38°C). • Limit test to 24 hours. After test, visually check system to be sure it is ready for operation. Notice: These parameters apply to Jandy Pro Series equipment only. For non-Jandy equipment, consult equipment manufacturer. -
Page 5: Section 2. General Information
This manual contains information for the proper installation 50 psi. Working pressures above 50 psi can cause and operation of the DEV Jandy Diatomaceous Earth (DE) product failure or also cause the filter lid to be blown Filters. Procedures in this manual must be followed exactly. -
Page 6: Section 3. Installation Instructions
Page 6 ENGLISH Jandy DE Pool Filters Installation & Operation Manual ® Section 3. Installation Instructions If the filter needs to be located above the water level of the pool, it can be raised 2.5 ft. without affecting the pump efficiency. A check valve is WARNING recommended on the suction line to the pump. -
Page 7: Filter Plumbing
Page 7 Jandy DE Pool Filters Installation & Operation Manual ENGLISH ® #12x1” Stainless Steel Pan Filter Base Head Screws (Qty 2) Drill Two 3/32” Holes #12x1” Pan Head Through Filter Base Stainless Steel Mounting Tab Mounting Bracket Screw (Qty 8) 1/4”... -
Page 8: Clamp Installation, Dev Series
Page 8 ENGLISH Jandy DE Pool Filters Installation & Operation Manual ® Support the inlet/outlet pipes independently to Housing prevent any undue strains on the filter's two (2) or three (3) port diverter valve. O-Ring Connect the pipes using the unions supplied with Tank Adapter the filter. -
Page 9: Section 4. Start-Up And Operation
Page 9 Jandy DE Pool Filters Installation & Operation Manual ENGLISH ® WARNING Changing the two (2) or three (3) port diverter valve handle while there is pressurized air in the system can cause product failure or also cause the filter lid to be... -
Page 10: Coating The Filter Grids
Page 10 ENGLISH Jandy DE Pool Filters Installation & Operation Manual ® Watch the pressure gauge to be sure that the Table 2. DE Slurry Mixture pressure does not exceed 50 psi in the filter for Model No. DE Quantity No. -
Page 11: Section 5. Filter Disassembly And Assembly
Page 11 Jandy DE Pool Filters Installation & Operation Manual ENGLISH ® While the DE filter grid assembly is out of the WARNING filter tank, rinse the inside of the tank with water. Replace drain plug. NEVER attempt to assemble, disassemble or adjust the filter when Gently rinse the grids with water. -
Page 12: Section 6. Maintenance
Page 12 ENGLISH Jandy DE Pool Filters Installation & Operation Manual ® Backwashing Place the tie rod knob on the tie rod and tighten. Tighten until the filter grid assembly is snug. With the filter pump off, set the backwash valve Do not overtighten. -
Page 13: Cleaning Filter Grids With Muriatic Acid
Page 13 Jandy DE Pool Filters Installation & Operation Manual ENGLISH ® Section 8. Troubleshooting WARNING For a list of common problems and solutions, see Working with muriatic acid can be dangerous. When the Troubleshooting Guide on the following page. - Page 14 Page 14 ENGLISH Jandy DE Pool Filters Installation & Operation Manual ® Table 4. Troubleshooting Guide Fault Symptom Possible Problems Solutions Water is not clear. Insufficient disinfectant level. Check and adjust disinfectant level. Incorrect pool chemistry. Test and adjust water chemistry.
-
Page 15: Section 9. Parts List And Exploded View
Jandy DE Pool Filters Installation & Operation Manual ENGLISH ® Section 9. Parts List and Exploded View of Jandy DEV Filter Exploded View Jandy DEV Filter Parts List Description Part No. Handle Assembly w/ Hardware (set of 2) R0357100 Handle Hardware (set of 4) -
Page 16: Section 10. Head Loss Curves
Section 10. Head Loss Curves 10.1 Jandy DEV Filter Design Head Loss Curves ® DEV48 DEV60 Design Design Head Pressure Loss Drop (ft head) (psi) Flow Rate (gpm) Zodiac Pool Systems LLC 2882 Whiptail Loop East #100, Carlsbad, CA 92010 1.800.822.7933 | www.ZodiacPoolSystems.com...
