APPENDIX A: VideoBloX Chassis Interlink Expansion

5 APPENDIX A: VideoBloX Chassis Interlink Expansion

Introduction

This chapter describes how to use chassis interlink input and output modules. Use the
chassis interlink input and output modules to allow multiple chassis to be connected
together, increasing the number of inputs of a matrix switching system.

Interlink Input and Output Modules

HVB32LKI-- Video Interlink Input Module 32 interlinks for interconnecting chassis.

Figure 5-1 HVBLKI Module
