Power

MTCBA-E1-EN2
Sleep:0.175A,1.6W@9V,
0.090A,1.8W@ 20V,
0.060A,1.9W @ 32V
Typical: 0.277A, 2.5W@9V,
0.133A, 2.7W@ 20V,
0.089A, 2.8W @ 32V
Max: 0.506A, 4.5W @ 9V,
0.240A, 4.8W @ 20V,
0.150A, 4.8W @ 32V
Peak: 2.50A @ 9V, 1.00A @ 20V,
0.60A @ 32V
MTCBA-E1-EN2-GP
Sleep:0.188A,1.7W @ 9V,
0.095A,1.9W @ 20V,
0.061A,1.9W @ 32V
Typical: 0.297A, 2.7W @ 9V,
0.138A, 2.8W @ 20V,
0.092A, 2.9W @ 32V
Max: 0.513A, 4.5W @ 9V,
0.240A, 4.8W @ 20V,
0.152A, 4.8W @ 32V
Peak: 2.50A@ 9V, 1.000A@ 20V,
0.625A@ 32V
NOTE: Multi-Tech Systems, Inc. recommends that the customer incorporate a 10% buffer into their power source when determining product load.

RF Specifications

GSM 850
Frequency RX 869 to 894 MHz
Frequency TX 824 to 849 MHz
RF Power Stand 2W at 12.5% duty cycle
Multi-Tech Systems, Inc. MultiModem rCell User Guide
MTCBA-C1-EN2
Sleep: 0.186A,1.7W @ 9V,
0.091A,1.8W @ 20V,
0.061A, 2.0W @ 32V
Typical: 0.283A, 2.6W @ 9V,
0.137A, 2.7W @ 20V,
0.088A, 2.8W @ 32V
Max: 0.457A, 4.1W, @ 9V,
0.214A, 4.3W, @ 20V,
0.138A, 4.4W @ 32V
MTCBA-C1-EN2-GP
Sleep: 0.186A,1.7W @ 9V,
0.091A,1.8W @ 20V,
0.061A,2.0W @ 32V
Typical: 0.384A, 3.5W @ 9V,
0.193A, 3.9W @ 20V,
0.122A, 3.9W @ 32V
Max: 0.541A, 4.8W, @ 9V,
0.256A, 5.1W, @ 20V,
0.162A, 5.2W @ 32V
EGSM 900
925 to 960 MHz
880 to 915 MHz
2W at 12.5% duty cycle
MTCBA-G2-EN2
Sleep:0.163A,1.5W @ 9V,
0.082A,1.6W @ 20V,
0.055A,1.8W @ 32V
Typical: 0.240A, 2.2W @ 9V,
0.114A, 2.3W @ 20V,
0.077A, 2.5W @ 32V
Max: 0.340A, 3.0W @ 9V,
0.153A, 3.1W @ 20V,
0.100A, 3.2W @ 32V
Peak: 1.300A @ 9V,0.518A @
20V, 0.343A @ 32V
MTCBA-G2-EN2-GP
Sleep:0.195A,1.8W @ 9V,
0.099A,2.0W @ 20V,
0.066A,2.1W @ 32V
Typical: 0.285A, 2.6W @ 9V,
0.136A, 2.7W @ 20V,
0.093A, 3.0W @ 32V
Max: 0.408A, 3.7W @ 9V,
0.183A, 3.7W @ 20V,
0.120A, 3.8W @ 32V
Peak: 2.25A @ 9V, 0.960A@
20V, 0.650A @ 32V
GSM 1800 GSM 1900
1805 to 1800 MHz 1930 to 1990 MHz
1710 to 1785 MHz 1850 to 1910 MHz
1W at 12.5% duty cycle 1W at 12.5% duty cycle
Chapter 1 – Product Description and Specifications
MTCBA-H4-EN2
GSM 850
Sleep 0.205A, 1.89W @9v, 0.110A,
2.20W @20v, 0.068A, 2.18W @32v
Typical 0.240A, 2.21W @9v, 0.114A,
2.28W @20v, 0.077A, 2.46W @32v
Max 0.429A, 3.91W @9v, 0.153A,
3.06W @20v, 0.100A, 3.20W @32v
Peak 2.50A @9v, 0.812A @20v,
0.500A @32v
HSPA
Sleep 0.205A, 1.89W @9v, 0.110A,
2.20W @20v, 0.068A, 2.18W @32v
Typical 0.480A, 4.38W @9v, 0.230A,
4.60W @20v, 0.148A, 4.74W @32v
Max 0.640A, 5.79W @9v, 0.290A,
5.80W @20v, 0.190A, 6.08W @32v
MTCBA-H4-EN2-GP
GSM 850
Sleep 0.270A, 2.48W @9v, 0.130A,
2.60W @20v, 0.087A, 2.78W @32v
Typical 0.320A, 2.94W @9v, 0.160A,
3.20W @20v, 0.104A, 3.33W @32v
Max 0.590A, 5.37W @9v, 0.280A,
5.60W @20v, 0.180A, 5.76W @32v
Peak 2.50A @9v, 0.812A @20v,
0.500A @32v
HSPA
Sleep 0.270A, 2.48W @9v, 0.130A,
2.60W @20v, 0.087A, 2.78W @32v
Typical 0.540A, 4.93W @9v, 0.265A,
5.30W @20v, 0.172A, 5.50W @32v
Max 0.780A, 7.06W @9v, 0.370A,
7.40W @20v, 0.240A, 7.68W @32v
CDMA 800
869 to 894 MHz
824 to 849 MHz
-
MTCBA-EV2-EN2
CDMA2000
Sleep 0.125A, 1.15W @9v, 0.060A,
1.20W @20v, 0.044A, 1.41W @32v
Typical 0.215A, 1.98W @9v, 0.130A,
2.60W @20v, 0.085A, 2.72W @32v
Max 0.600A, 5.45W @9v, 0.297A,
5.94W @20v, 0.195A, 6.05W @32v
EV-DO
Sleep 0.125A, 1.15W @9v, 0.060A,
1.20W @20v, 0.044A, 1.41W @32v
Typical 0.335A, 3.08W @9v, 0.190A,
3.30W @20v, 0.125A, 4.00W @32v
Max 0.672A, 6.10W @9v, 0.320A,
6.40W @20v, 0.204A, 6.53W @32v
MTCBA-EV2-EN2-GP
CDMA2000
Sleep 0.245A, 2.26W @9v, 0.125A,
2.50W @20v, 0.083A, 2.66W @32v
Typical 0.340A, 3.12W @9v, 0.166A,
3.32W @20v, 0.110A, 3.52W @32v
Max 0.690A, 6.27W @9v, 0.330A,
6.60W @20v, 0.210A, 6.72W @32v
EV-DO
Sleep 0.0465A, 2.27W @9v, 0.125A,
2.50W @20v, 0.238A, 7.62W @32v
Typical 0.370A, 3.40W @9v, 0.220A,
4.40W @20v, 0.145A, 4.64W @32v
Max 0.780A, 7.13W @9v, 0.374A,
7.48W @20v, 0.385A, 7.62W @32v
CDMA 1900
1930 to 1990 MHz
1850 to 1910 MHz
-
