Multitech MultiModem rCell User Manual page 36

Chapter 4 – Using the Web Management Software
Caller ID Configuration
Add "Wakeup on Call" Caller ID:
Caller Acknowledgement Configuration
Acknowledgement String to Caller:
Submit
Click the SUBMIT button to save these settings.
Note: You must click Save and Restart once you have completed and submitted all the screens on which you have made
changes.
PPP > Wakeup-On-Call Examples
Example 1 – Set Up the Ethernet Router to Activate on Incoming SMS Message
1. On the PPP > PPP Configuration
PPP General
●
Make sure that PPP is Enabled (the default).
●
Make sure Dial-on-Demand is Enabled (the default).
●
Set the Idle Time Out to the number of seconds you desire.
Authentication
●
Your wireless service provider may require you to have a separate PPP Username and Password. If so, enter
them here. Note:
when you activated your account.
Modem Configuration
●
Make sure your Dial Number is entered correctly:
For GSM models, the Dial Number is *99***1#
For CDMA models, the Dial Number is #777
●
Enter your APN. The APN is assigned by your wireless service provider.
Example: AT+CGDCONT=1,"IP","Internet" The Example: AT+CGDCONT=1,"IP","Internet" needs to be removed.
Just the APN name needs to be entered in the APN field.
Submit
●
Click the Submit button to save the changes made on this screen.
2. On the PPP > Wakeup-on-Call
Wakeup-on-Call Configuration
●
Select Enable for Wakeup-on-Call.
●
Set the Time Delay. You can use the 10 second default.
●
Enter the Init Strings from the model dependent table described in the Wakeup-on-Call Configuration.
●
Click the Submit button to save these settings.
Caller ID Configuration
●
Enter an SMS that you want added to the Caller ID list.
Note: Add the SMS message string into the Caller ID list. The SMS message string must not contain any spaces
between words. When the configured string matches the SMS message string, it will activate the Wakeup-on-Call
feature.
●
Add Button
Click the Add button to save each message as it is entered into the Caller ID list.
Caller Acknowledgement Configuration
●
Enter a configured string (0 to 40 characters) that will be sent to the integrated cellular modem upon receiving a
valid Caller ID from the WAN.
Set the Wakeup Acknowledgement string configuration with the command at+cnma
●
Click the Submit button to save the Acknowledgement Configuration.
You must click Save and Restart once you have completed and submitted all the screens on which you have made
changes. The device will save all the settings and reboot the PC.
36
To add Caller ID to the Wakeup-on-Call function, enter the Caller ID to be
allowed to wakeup the router. Enter 'RING' (all Caps) to wake up on any call. Enter a CID phone
number or an SMS message. The SMS message string must not contain any spaces between
words.
After entering the Caller ID, click the Add button. The Caller ID displays at the bottom of screen.
You can enter any number of IDs you desire.
A Caller ID can be edited or deleted using Options, which will be available once a Caller ID is
displayed.
The configured string of (0 to 40 characters) will be sent to the integrated cellular
modem upon receiving a valid caller ID from the WAN. The default is NULL string.
Note: If the string is not configured, acknowledgement to the caller will not be sent upon successful
caller ID reception.
screen, set up the following parameters:
If a username and password are required, your wireless provider would have given them to you
screen, set up the following parameters:
Multi-Tech Systems, Inc. MultiModem rCell User Guide
