Chapter 2 – Installation
5. Screw-on the power lead from the power supply module into the power connection on the router. Now, plug the
power supply into your power source.
For Optional Direct DC Power
●
Screw-on the DC power cable to the power connector on the router.
●
Then attach the two wires at the other end of the DC power cable to a DC fuse/terminal block in which you are
mounting the router.
●
Connect the red wire to the "+" (positive) terminal and the black wire to the "–" (negative) terminal. Be sure
the GND connection is correct.
Warning: Over-voltage protection is provided on the device. To ensure complete protection, you may want to
add additional filtering to the DC input.
Note: For an application involving a battery: you can use permanent "+" or key-switched "+" source. Connect
the power supply to its source (for example, in a mobile situation, to the DC fuse/terminal block).
Notes
●
The POWER LED.
●
The Status
When the
● The
Reset Button.
the username and password back to admin and admin as well as setting the IP address to the default of
192.168.2.1.
Powering Down and Hardware Resetting a MTCBA-C1-EN2 Router
It is recommended to follow the following shutdown sequence, when possible, prior to a hardware
reset or turning off of power to the router.
The shutdown sequence informs the network that the mobile station is going offline, and saves
critical data to the module's non-volatile memory (flash).
AT+CFUN=0 (issue this command)
+WIND:10
Router is now ready to be powered off or reset.
If you do not see the +WIND:10 response, you may need to activate the unsolicited message by
using the command AT+WUSLMSK=00020000,0
14
The POWER LED lights after power-up.
LED is a solid ON when the router is booting up, saving a configuration, or updating firmware.
Status LED begins to blink, the router is ready.
Hold the Reset button in until the Status Light goes out. Then release it. It also will set
(Wait for this response from the modem)
