Chapter 3 – Carrier Activation

Verizon Wireless Networks Activation

1. Perform the Modem Activation procecures for Verizon Wireless Networks using the Verizon Wireless Networks Activation
Notice supplied with your product.
2. When you receive a response of WOT2: "Programming Successful" from the Over-the-air Service Programming session,
your router is successfully activated on your Verizon network.
Powering Down and Hardware Resetting a MTCBA-C1-EN2 Router
It is recommended to follow the following shutdown sequence, when possible, prior to a hardware
reset or turning off of power to the router.
The shutdown sequence informs the network that the mobile station is going offline, and saves
critical data to the module's non-volatile memory (flash).
AT+CFUN=0 (issue this command)
+WIND:10
Router is now ready to be powered off or reset.
If you do not see the +WIND:10 response, you may need to activate the unsolicited message by
using the command AT+WUSLMSK=00020000,0

Sprint Network Activation

1. Perform the Sprint Network Activation procedures using the Sprint Modem Activation Notice supplied with your product.
2. To verify status of the activation, enter command, AT+WDSW? If the modem responds with 12,1, your activation is
successful.
If the modem responds with 12,0, the modem may be trying to activate, wait for five minutes. If after 5 minutes, refer to
Appendix F, Sprint Activation Failure Corrective Action and perform the Manual Activation procedure.
On some occasions, the modem response +WIND: 4 indicates that a successful completion, but you cannot acquire a data
connection. Refer to Appendix F, Sprint Activation Failure Corrective Action and perform the Manual Activation procedure.
Powering Down and Hardware Resetting a MTCBA-C1-EN2 Router
It is recommended to follow the following shutdown sequence, when possible, prior to a hardware
reset or turning off of power to the router.
The shutdown sequence informs the network that the mobile station is going offline, and saves
critical data to the module's non-volatile memory (flash).
AT+CFUN=0 (issue this command)
+WIND:10
Router is now ready to be powered off or reset.
If you do not see the +WIND:10 response, you may need to activate the unsolicited message by
using the command AT+WUSLMSK=00020000,0

GSM Network Activation

The Multi-Tech router configured for a GSM network has been preconfigured for the GSM network. Follow the process directed
by the GSM Modem Activation Customer Notice and obtain a wireless account with your provider/partner/reseller and/or SIM
card. Once you have an activated SIM and it is installed in the router, the router is ready for use.

Exiting Modem Mode

1. After the last AT Command is entered, press:
CTRL + ] (the right bracket).
2. The following prompt displays:
telnet>
Type quit and press Enter.
3. Then the following prompt displays:
c:>
Type exit and press Enter.
22
(Wait for this response from the modem)
(Wait for this response from the modem)
