Chapter 1 – Product Description and Specifications

Specifications

MTCBA-E1-EN2
Features
Performance EDGE: E-GPRS Class 12,
GPRS: Class 10
Band, Frequency Quad-band GSM/GPRS/EDGE
850/900/1800/1900 MHz
Packet Data EDGE: E-GPRS Up to 240K bps,
coding scheme MCS1-9, mobile
station Class B, LLC layer, 4 time
slots
GPRS: Full PBCCH support,
coding scheme 1-4, mobile station
Class B
Circuit-Switched
Up to 14.4K bps, non-transparent
Data
Short Message Text & PDU, Point-to-Point
Services-SMS (MO/MT), cell broadcast
Antenna RF Antenna: 50 ohm SMA (female
Connector connector)
SIM Connector Standard 1.8 and 3V SIM
receptacle
RS232 Connector
Power Connector
Voltage
Physical
Description
Operating
-35° to +75° C*
Temperature *
Storage Temp
Humidity
Certifications
EMC Compliance
FCC Part 15
EN55022
EN55024
Radio Compliance
FCC Part 22, 24
RSS132,133
EN301 489-1
EN489-3 (-GP only)
EN301 489-7
EN301 511
AS/ACIF S042.1, S042.3
Safety: UL60950-1
cUL60950-1
IEC60950-1
Network: PTCRB
*
UL Listed @ 40° C, limited by power supply. UL Certification does not apply or extend to an ambient above 40° C and has not been evaluated by UL for ambient greater than 40° C.
"UL has evaluated this device for use in ordinary locations only. Installation in a vehicle or other outdoor locations has not been evaluated by UL. UL Certification does not apply or extend to use
in vehicles or outdoor applications or in ambient above 40° C."
10
MTCBA-C1-EN2
CDMA2000 1xRTT GPRS Class 10
Dual-band 800/1900 MHz CDMA; Quad-band GSM
800 MHz and 800/1900 MHz with
850/900/1800/1900 MHz
R-UIM support
Up to 153.6K bps forward and Up to 85.6K bps, coding schemes
reverse CS1 to CS4
IS-95A, IS-95B up to 14.4K bps Up to 14.4K bps transparent and
forward and reverse non-transparent
Text & PDU, Point-to-Point Text & PDU, Point-to-Point, cell
(MO/MT), cell broadcast broadcast
RF Antenna: 50 ohm SMA (female RF Antenna: 50 ohm SMA
connector) (female connector)
- Standard 1.8 and 3V SIM
receptacle
7"W x 1.24"H x 2.93"D 0.75lbs 17.78cmW x3.15cmH x7.44cmD 0.340Kg
-40° to +85° C*
Relative humidity 20% to 90% noncondensing
EMC Compliance EMC Compliance
FCC Part 15
Radio Compliance
FCC Part 22, 24
Radio Compliance
RSS132,133
Safety: UL60950-1
cUL60950-1
IEC60950-1
Network: CDG 1&2
Safety:
Network:
MTCBA-G2-EN2
HSPA
HSUPA / HSDPA / UMTS Triple-
band: 2100/1900/850 MHz with Rx
diversity
HSDPA data service of up to
7.2 Mbps
HSUPA data service of up to
5.76 Mbps
Up to 14.4K bps transparent and
non-transparent
Text & PDU, Point-to-Point
(MO/MT), cell broadcast
RF Antenna: 50 ohm SMA (female
connector)
Standard 1.8 and 3V SIM
receptacle
DE9
2.5mm miniature (screw-on)
9V to 32 VDC
-40° to +85° C*
-40° to +85° C
EMC Compliance
FCC Part 15 FCC Part 15
EN55022 EN55022
EN55024 EN55024
Radio Compliance
FCC Part 22, 24 FCC Part 22, 24
RSS132,133 RSS132,133
EN301 489-1 EN301 489-1
EN489-3 (-GP only)
EN489-3 (-GP only)
EN301 489-7 EN301 489-7
EN301 511 EN301 511
AS/ACIF S042.1, S042.3 AS/ACIF S042.1, S042.3
UL60950-1 Safety:
cUL60950-1
IEC60950-1
AS/NZS60950-1 Network:
PTCRB
Multi-Tech Systems, Inc. MultiModem rCell User Guide
MTCBA-H4-EN2 MTCBA-EV2-EN2
CDMA2000 1xRTT
EV-DO Rev. A
Dual-band 800/1900 MHz CDMA;
800 MHz and 800/1900 MHz with
R-UIM support
Peak download 3.1 Mbps, peak
upload 1.8 Mbps
IS-95A, IS-95B up to 14.4K bps
forward and reverse
Text & PDU, Point-to-Point
(MO/MT), cell broadcast
RF Antenna: 50 ohm SMA (female
connector)
-30° to +60° C* -40° to +75° C*
EMC Compliance
FCC Part 15
Radio Compliance
FCC Part 22, 24
RSS132,133
Safety: UL60950-1
cUL60950-1
IEC60950-1
Network: CDG 1&2
UL60950-1
cUL60950-1
IEC60950-1
PTCRB
-
