Chapter 4 – Using the Web Management Software
Submit
●
Click the Submit button to save the changes made on this screen.
2. On the PPP > Wakeup-on-Call
Wakeup-on-Call Configuration
●
Select Enable for Wakeup-on-Call.
●
Set the Time Delay. You can use the 10 second default.
●
Enter the Init Strings:
●
Submit Button
Click the Submit button to save these settings.
Caller ID Configuration
●
Enter a caller's ID that you want added to the Caller ID list.
●
Add Button
Click the Add button to save each Caller ID as it is entered to the Caller ID list.
3. Save and Restart
Click Save and Restart once you have completed and submitted all the screens on which you have made
changes. The device will save all the settings and reboot the PC.
PPP > Power-On Configuration
The Power-On Configuration feature allows you to set an initialization string that will be sent to the router upon boot up.
Power-On Init String Configuration
Power-On Init String:
Submit:
38
screen, set up the following parameters:
Set Wakeup Init String 1 by entering AT+CLIP=1
You can enter a string of 0 to 40 characters that will be sent to the router upon boot up. All
commands will initialize before you proceed with regular PPP related activity.
Note: When no initialization string is configured, regular functionality of the router is retained.
Click the SUBMIT button to save this setting.
Note: You must click Save and Restart once you have completed and submitted all the
screens on which you have made changes.
