Specifications

Features
Standard
Band, Frequency
Packet Data
Circuit-Switched Data
Short Message Services (SMS) Text & PDU, Point-to-Point (MO/MT), cell broadcast
Antenna Connector
SIM Connector
Power Connector
Voltage
Physical Description
Operating Temperature
1
Storage Temp
Humidity
Certifications
1
UL Listed @ 40°C. Limited by power supply. UL Certification does not apply or extend to an ambient above 40°C
and has not been evaluated by UL for ambient greater than 40°C
UL has evaluated this device for use in ordinary locations only. Installation in a vehicle or other outdoor locations
has not been evaluated by UL. UL Certification does not apply or extend to use in vehicles or outdoor applications
or in ambient above 40° C.
Note: Radio performance may be affected by temperature extremes. This is normal. The radio is designed to
automatically fallback in class and reduces transmitter power to avoid damage to the radio. When this
occurs depends on the interaction of several factors, such as ambient temperature, operating mode,
and transmit power.
Multi-Tech Systems, Inc. MultiModem rCell User Guide
HSPA
HSPA/HSDPA/UMTS quad-band: 2100/1900/900 MHz;
GSM/GPRS/EDGE: 900/1800/900/850
HSDPA data service of up to 7.2 Mbps; HSUPA data service of up to 5.76 Mbps
Up to 14.4K bps, non-transparent
RF Antenna: 50 ohm SMA (female connector)
Standard 1.8 and 3V SIM receptacle
2.5mm miniature (screw-on)
5 VDC
6.50" W x 1.59" H x 3.34" D 11.5 oz (16.51cm W x 4.04cm H x 8.48cm D 326g)
1 -30° to +60° C
-40° to +85° C
Relative humidity 20% to 90% noncondensing
EMC Compliance
FCC Part 15 Class B
EN55022 Class B
EN55024
Radio Compliance
FCC Part 22, 24
RSS132,133
EN301 489-1
EN489-3 (-GP only)
EN301 489-7
EN301 489-24
AS/ACIF S042.1, S042.3
Safety
nd
UL60950-1, 2 Edition
IEC60950-1:2005 (Second Edition with
EN 60950-1:2006+A11:2009
Network
PTCRB
AT&T
Chapter 1 – Introduction and Description
MTCBA-H3-EN3
9
