BOBBIN WINDING
BOBBIN WINDING THROUGH THE NEEDLE
Make sure that the presser foot and the needle are in the up
position.
1.
Place an empty bobbin on the bobbin spindle on the
top of the machine. The bobbin only ts on one way,
with the logo facing up. Use only original HUSQVARNA
VIKING® bobbins.
2.
Thread the machine with the main spool pin in the
horizontal position.
Note: If the thread spool is too large to be in horizontal
position, wind the bobbin as described under "Winding Specialty
Threads" below.
3.
Bring the thread up from the needle, under the presser
foot and up to the right through thread guide (A).
Note: Use a metal presser foot when bob bin winding from the
needle.
4.
Guide the thread through the hole in the bobbin from
the inside to the outside.
5.
Push the bobbin winder lever towards the bobbin to
wind. A pop-up message appears on screen. To adjust
winding speed drag the arrow on the slider with your
stylus. Stop and start the bobbin winding with the
on-screen buttons. Hold the end of the thread rmly
when starting to wind. Once the bobbin begins to
wind, cut the excess thread.
Note: It is important that you cut the thread end close to the bobbin.
When the bobbin is full, the bobbin winder lever will
move back and the winding will stop automatically.
The pop-up message closes. Remove the bobbin and
cut the thread using the bobbin winding thread cutter.
Winding Specialty Threads
We do not recommend winding speciality threads such as
"invisible" or other stretchy threads, metallic or at metallic
threads through the needle.
Always wind these threads at minimum speed.
1.
Place an empty bobbin on the bobbin spindle at the
front of the machine. The bobbin only ts on one way,
with the logo facing up. Use only original HUSQVARNA
VIKING® bobbins.
2.
Place the large spool cap and a felt pad under the
spool on the main spool pin set in the vertical position.
3.
Bring the thread over the Pre-Tension Thread guide
(B) and down around the thread tension disc (C), then
through thread guide (D) as illustrated.
4.
See Bobbin Winding Through the Needle, step 4-5.
2:6
A
Note: When using earlier version of HUSQVARNA VIKING®
bobbins that do not have a hole, wind several turns of thread on the
bobbin to get started.
B
C
D
