PROGRAM
You can combine stitches and/or letters and numbers to create stitch programs. Combine various decorative stitches and
stitch fonts from the machine or from an external device.
You can program stitches up to approximately 500mm (20") long. You can see how long your actual stitch program is at
the bottom of the window.

IMPORTANT PROGRAM MODE INFORMATION

Program can be used in either Sewing Mode or Embroidery Mode. A stitch program created when Embroidery Mode is
active will become an embroidery design when saved and cannot be sewn as a stitch in Sewing Mode.
A stitch program created when Sewing Mode is active will not be available when opening Program mode after activating
Embroidery Mode and vice versa. The created stitch program will not be transferred to the other mode.
Note: If Sewing Mode is active and your stitch program is ready to be sewn, you can also close the active function by pressing the foot control, or
by pressing the Start/Stop button. Not all stitches are available to program. A pop-up message will notify you if you try to select an unavailable
stitch.
Note: A straight line at the point of the Scroll Up or Down icon indicates scroll to beginning or end.

PROGRAM - OVERVIEW OF ICONS

Stitch Menu
Scroll Up
Scroll Down
Cursor
Duplicate
Delete
Mirror End-to-End
Stitch Length
Mirror Side-to-Side
Stitch Width
ALT
Program Length
5:2
Font Menu Load from le Information
Quick Help
Save to My Files
Save to My Stitches
Horizontal Preview
