REMOVE THE EMBROIDERY UNIT

1. To store the embroidery unit in the embroidery case,
move the embroidery arm to Park Position by selecting
Park Position on the screen in either Embroidery Edit
or Embroidery Stitch-Out.
2. Press the button at the left, underneath the embroidery
unit (A) and slide the unit to the left to remove it.

TO HOOP THE FABRIC

For the best embroidery results, place a layer of stabilizer
beneath the fabric. When hooping stabilizer and fabric
make sure that they are smooth and securely hooped.
1. Open the Quick Release (B) on the outer hoop and
loosen the screw (C). Remove the inner hoop. Place
the outer hoop on a rm at surface with the screw on
the lower right. There is a small arrow in the center of
the lower edge of the hoop which will line up with a
small arrow on the inner hoop.
2. Place the stabilizer and fabric, with the right sides
facing up, on top of the outer hoop. Place the inner
hoop on top of the fabric with the small arrow at the
bottom edge.
3. Push the inner hoop rmly into the outer hoop.
4. Close the Quick Release (B). Adjust the pressure of
the outer hoop by turning the retaining screw (C). The
fabric should be taut in the hoop for the best results.
Note: When embroidering additional designs on the same fabric, open
the quick release, move the hoop to the new position on the fabric and
close the quick release. When changing type of fabric, you might need
to adjust the pressure using the retaining screw. Do not force the quick
release.
A
C
B
E S U
MBROIDERY ET P
6:3
