Stitch Positioning

On certain stitches, for example straight stitch, the stitch width icon

becomes a stitch position icon. Use + to move the stitch to the right

and - to move the stitch to the left when using a straight stitch. The

machine has a maximum of 29 needle positions (for a straight stitch).

When ALT is selected on a stitch that has width the edge position of

the stitch can be moved from right to left.The stitch position can only

be changed to the limit of the maximum stitch width. Changing the

stitch position will also limit the stitch width adjustment.

Stitch Width

Decrease or increase the stitch width using -and +. Default settings are

shown in black numbers, adjusted settings in red.

Stitch Length

Increase or decrease the stitch length using + and -. If lengthening a

zigzag stitch or a decorative stitch, the entire stitch will be longer. If

lengthening a satin stitch where the density can be adjusted, the entire

stitch will be longer but the density will remain the same.

Note: The set stitch width and the stitch length are shown between the + and -.

When trying to exceed minimum or maximum settings for width and length, a

Stitch length -

Stitch length +

warning sound will be heard.

The default setting is shown in black. Changed settings are shown in red.

Button Size

When sewing a buttonhole with the Sensor One-Step buttonhole

foot, you can set the button size. Measure your button and enter the

button size in the button size control.

Button Sew On

When sewing a button, you can set the number of stitch repeats.

Touch the + or -to increase or decrease the number of stitch repeats

(see 4:14).

Stitch Density

The stitch density control adjusts the density (the distance between

the individual satin stitches that make up the entire stitch). The

density does not affect the actual length of the entire stitch.

Touch + to increase the value. Touch - to decrease the value.

Note: This is often used with specialty threads and when a less dense satin stitch

Stitch density +

Stitch density -

is desired.

Mirroring

To mirror stitches or stitch programs sidewise touch Mirror Side-

Mirror End-to-End

to-Side icon. For mirroring the stitch or stitch programs lengthwise

touch Mirror End-to-End icon.

Note: Buttonholes cannot be mirrored.

Mirror Side-to-Side
