RESIZE

Resize can reduce an embroidery design up to ve times
smaller than the original design or increase it up to
eight times larger than the original design. The machine
recalculates the number of stitches in the design so the
original stitch density remains.
Note: To reduce or increase the design less than 20%, use Scale
function. The Scale function does not change the stitch count.
Resize Adjustments
Select the design you want to resize. Open the Resize
window. Adjust the design size by touching and dragging
on the screen or by using the Control. The size of the
design is shown in millimeters above the Control. To return
to the original size, touch the Control center icon. Adjust
the placement of the design in the hoop using Position and
Rotate.
Retain Fill Type
All ll areas in an embroidery design are made in a speci c
type to get the best effect. When enlarging or reducing a
design, the stitches in the ll area will be affected.
There are two ways to handle the ll type and style in the
design to be resized.
1. The default setting will not retain ll type. This is the
fastest way to resize a design. However, the ll areas in
the design may look different than the original.
2. When Retain Fill Type is selected, it will take longer to
resize but the process will retain the ll types and styles
within the design areas. If greatly enlarging a design,
Retain Fill Type is recommended for best results.
To Start Resizing
When you are satis ed with the design size and position,
touch OK to close the window and start resizing. An
hourglass on the screen shows that it is working. When
nished, the resize window will close.
Touch Cancel to return to Embroidery Edit without
resizing.
Note: Stitches and stitch programs cannot be resized.
7:4
Pan
Rotate Resize
Position
Control
Retain Fill Type
Enlarge
design
Reduce
design
center
