View Anywhere display

The View Anywhere display option enhances outdoor viewing and bright-light viewing
environments. The View Anywhere display includes all the features of the standard display
plus:
•
A protective layer that improves the sunlight contrast ratio and significantly reduces
reflection and glare.
•
Improved sunlight contrast ratio, which enhances viewability at wide viewing angles.
•
Reduced reflection and glare and improved light pass-through efficiency.

Other optional features

Other C5v/F5v features are described later:
•
Web and documentation cameras,"Using the cameras (optional)" on page 34
•
Barcode scanner, "Using the barcode scanner (optional)" on page 36
•
RFID reader, "Using the RFID reader (optional)" on page 37
•
Smart card reader, "Using the smart card reader (optional)" on page 49

Overview of the C5v/F5v

The following illustrations show the buttons, slots and ports on the C5v/F5v Tablet PC.
Top side
RFID button
RFID status
light
Chapter 1 Getting Started
barcode
scanner button
RFID (optional) Shows the status of the RFID reader.
status light
RFID reader Use to trigger the RFID reader.
(optional) button
Barcode scanner Use to trigger the barcode scanner.
(optional) button
Fan cover Protects the fan assembly.
fan cover
Overview of the C5v/F5v 3
