CFT-Series Docking Station User’s Guide CFT-001/CFT-002/CFT-003 Station d’accueil Guide de l’utilisateur Docking-Station Benutzerhandbuch Estación base Guía del usuario Base de encaixe Guia do Usuário...
Page 3
Unidos e/ou outros países. Motion Computing, Inc. ha realizado todos los A Motion Computing, Inc. fez todo o esforço possível esfuerzos razonables para identificar las propiedades para identificar as propriedades e proprietários de de marcas comerciales y sus propietarios en esta marcas registradas nesta página.
Contents Docking Station ......1 Placing and mounting the Docking Station ....2 Placing on a desk or table.
Page 6
Utilisation d’un moniteur externe et d’un projecteur..24 Utilisation de la baie de chargement de la batterie ..25 Changement de batterie lorsque la tablette est sur la station d’accueil ........26 Garantie .
Page 7
Lectura de las luces de estado ......48 Acoplamiento y retirada del tablet ..... . .49 Configuración del ángulo de visión .
Docking Station This document applies to the docking station for the Tablet PC models CFT-001, CFT-002, and CFT-003. To determine which tablet model you have, refer to the label on the back of the unit. The Docking Station adds functionality to your tablet, including port expansion for Ethernet, VGA monitors, and USB devices such as printers, keyboards, and mice.
Placing and mounting the Docking Station You can place the Docking Station on a desk or table, or mount it to a wall, cart, arm mount, or other equipment. The bottom of the Docking Station has a standard VESA mounting pattern that can be used with other VESA-compatible equipment.
Mounting to a cart or mounting arm Mounting the Docking Station to a cart or mounting arm requires a VESA-compatible mount to interface with the 75 mm VESA hole pattern on the bottom of the Docking Station. For information about viewing angles of the Docking Station, see “Setting the viewing angle”...
Connecting the Docking Station The Docking Station includes ports for extending the capabilities of your tablet and charging the battery. To connect to the Docking Station ports 1. Connect the power adapter as shown in the following illustration. Docking Station...
Page 13
2. Connect peripherals such as a keyboard or mouse to the USB ports. Note: The ports on the Docking Station can be powered by the tablet’s battery or by AC power. AC power port USB ports Ethernet port Security slot VGA port 3.
Using the Docking Station After you have mounted the Docking Station and attached peripherals, you can use the Docking Station to enhance the performance of your tablet. Reading the status lights The lights on the front of the Docking Station indicate its status. Status lights Green: Tablet is docked Off: Tablet is not docked...
Docking and removing the tablet You can easily insert and remove the tablet from the Docking Station. To dock the tablet • Gently slide the tablet into the Docking Station. The tablet locks into place when cradled securely. The green docking light indicates a successful dock. Docking Station...
To remove the tablet The tablet can be removed from the Docking Station in two ways: • Press the eject button, and then pull the tablet out of the Docking Station. Eject button • Hold the Docking Station with one hand and pull the tablet out of the Docking Station.
Locking the Docking Station The security slot locks the Docking Station only, not the tablet. To lock the Docking Station 1. Locate the security slot on the Docking Station. Security slot 2. Open and place your lock in the security slot. 3.
Using an external monitor and projector You can connect the Docking Station to a VGA monitor or projector for presentations. The tablet supports various external monitor configurations, including extended and mirrored display. To use a VGA monitor 1. Connect the monitor cable to the VGA port on the Docking Station.
Using the battery charging bay The battery charging bay at the rear of the Docking Station enables you to charge the tablet and a spare battery at the same time. • To charge the tablet, place the tablet into the Docking Station. •...
You can change the battery in the tablet while the tablet is on and docked. WARNING: (Models CFT-001 and CFT-002 only) Avoid lifting the tablet and disconnecting the tablet from the docking connector on the Docking Station, which will cause a power loss to the tablet.
Warranty This product comes with a limited warranty. To see details about this limited warranty, go to www.motioncomputing.com. Safety and regulatory For general safety information, see the Safety and Regulatory Guide packaged with your tablet. FCC Notice (United States): This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
2 (IEC 61000 3-2), EN 61000 3-3 (IEC 61000 3-3), EN60950 (IEC 60950 3rd Ed; 1999; 2000). Service and support For service and support, go to www.motioncomputing.com/support. Patents The Motion Computing products and services may be covered by one or more protected inventions. For more information, see www.motioncomputing.com/info/patents.asp. Docking Station...
Station d’accueil Ce document s’applique à la station d’accueil des modèles de tablette PC CFT-001, CFT-002 et CFT-003. Pour déterminer quel est votre modèle, référez-vous à l’étiquette apposée à l’arrière de la tablette. La station d’accueil apporte d’autres fonctionnalités à votre tablette, notamment une extension de port pour connectivité...
Positionnement et montage de la station d’accueil La station d’accueil peut être placée sur un bureau ou une table, ou être montée sur un mur ou tout autre équipement de type accoudoir ou chariot. La partie inférieure de la station contient un élément de montage VESA standard, pouvant être fixé...
Montage sur un chariot ou un accoudoir Pour monter la station d’accueil sur un chariot ou un accoudoir, vous devez utiliser un support compatible VESA, qui servira d’interface avec le support à trou VESA 75 mm de la station. Pour plus d’informations sur les angles de vision de la station d’accueil, consultez la section «...
Connexion de la station d’accueil La station possède des ports permettant d’étendre les capacités de la tablette et de recharger la batterie. Pour se brancher sur les ports de la station d’accueil 1. Branchez l’adaptateur secteur conformément à l’illustration ci- dessous.
Page 27
2. Branchez les périphériques souhaités (clavier ou souris) sur les ports USB. Remarque : Les ports de la station d’accueil peuvent être alimentés par batterie (tablette) ou sur secteur. Port pour alimentation CA Ports USB Port Ethernet Fente de sécurité Port VGA 3.
Utilisation de la station d’accueil Une fois la station montée et les principaux périphériques branchés, vous pouvez utiliser la station pour améliorer les performances de votre tablette. Description des voyants d’état Les voyants situés à l’avant de la station d’accueil indiquent son état.
Placement et retrait de la tablette Vous pouvez insérer la tablette dans la station d’accueil et l’en retirer aisément. Pour placer la tablette sur la station • Faites glisser délicatement la tablette dans la station d’accueil. La tablette doit se bloquer lorsqu’elle est correctement mise en place.
Pour retirer la tablette de la station Il existe deux méthodes pour sortir la tablette de la station d’accueil : • Appuyez sur le bouton d’éjection, puis tirez la tablette hors de la station. Bouton d’éjection • Tout en maintenant la station d’une main, tirez sur la tablette pour la sortir.
Si vous utilisez un clavier avec votre station, lorsque la tablette est insérée, choisissez un angle de 25° ou 38°. Verrouillage de la station d’accueil La fente de sécurité protège uniquement la station et non la tablette. Pour verrouiller la station d’accueil 1.
Utilisation d’un moniteur externe et d’un projecteur Vous pouvez brancher la station d’accueil à un moniteur VGA ou à un projecteur, afin de réaliser des présentations. Votre tablette prend en charge plusieurs configurations de moniteur externe, notamment en affichage étendu et en miroir. Pour utiliser un moniteur VGA 1.
Utilisation de la baie de chargement de la batterie La baie de chargement située à l’arrière de la station d’accueil vous permet de charger simultanément la batterie de votre tablette et une batterie supplémentaire. • Pour recharger la tablette, placez-la sur la station d’accueil. •...
Vous pouvez changer la batterie de la tablette alors que celle-ci est en marche et placée sur la station d’accueil. AVERTISSEMENT : (Modèles CFT-001 et CFT-002 uniquement) Evitez de retirer la tablette et de la déconnecter du connecteur d’ancrage de la station, car ceci entraînerait une perte d’alimentation pour la tablette.
Garantie Ce produit est fourni avec une garantie limitée. Pour obtenir plus de détails sur cette garantie limitée, rendez-vous sur le site www.motioncomputing.com. Sécurité et réglementation Pour obtenir des informations générales en matière de sécurité, reportez-vous au Guide des conseils de sécurité et réglementations fourni avec la tablette.
Pour obtenir une assistance technique ou des informations sur nos services, rendez-vous sur le site www.motioncomputing.fr/support. Brevets Les produits et services de Motion Computing peuvent être protégés par une ou plusieurs inventions brevetées. Pour plus d’informations, consultez le site www.motioncomputing.com/ info/patents.asp.
Dockingstation Dieses Dokument bezieht sich auf die Dockingstation für die Tablet PC-Modelle CFT-001, CFT-002 und CFT-003. Wenn Sie wissen möchten, wie Ihr Tablet-Modell lautet, lesen Sie das Etikett auf der Rückseite Ihres Tablet PCs. Die Dockingstation erweitert die Funktionalität Ihres Tablets PCs.
Positionieren und Montieren der Dockingstation Die Dockingstation kann auf einem Schreibtisch oder einem anderen Tisch aufgestellt bzw. an der Wand oder anderen Vorrichtungen befestigt werden. Auf der Unterseite der Dockingstation befinden sich Montagevorrichtungen gemäß VESA-(Video Electronics Standards Association-)Standard, die mit anderen diesem Standard entsprechenden Vorrichtungen verwendet werden können.
Befestigen an einem Wagen oder Befestigungsarm Für das Befestigen der Dockingstation an einem Wagen oder Befestigungsarm ist eine Vorrichtung gemäß VESA-Standard erforderlich, die der 75-mm-VESA-Lochung an der Unterseite der Dockingstation entspricht. Informationen zu den Sichtwinkeln der Dockingstation finden Sie unter “Einstellen des Sichtwinkels“ auf Seite 36. So montieren Sie die Dockingstation 1.
Anschließen der Dockingstation Die Dockingstation verfügt über Anschlüsse, die den Funktionsumfang Ihres Tablet PCs erweitern und zudem das Laden des Akkus ermöglichen. So nehmen Sie den Anschluss an den Anschlüssen der Dockingstation vor 1. Verbinden Sie den Netzadapter wie in folgender Abbildung dargestellt.
Page 41
2. Verbinden Sie Peripheriegeräte, beispielsweise eine Tastatur oder Maus, mit den USB-Anschlüssen. Hinweis: Die Anschlüsse an der Dockingstation können vom Akku des Tablet PCs oder mit Netzstrom betrieben werden. Netzanschluss USB-Anschlüsse Sicherheitsschlitz Ethernet-Anschluss VGA-Anschluss 3. Falls gewünscht, können Sie zum Sichern der Dockingstation ein für den Sicherheitsschlitz passendes Schloss im Kensington-Stil verwenden.
Verwenden der Dockingstation Nach erfolgter Montage der Dockingstation und Anschluss der Peripheriegeräte können Sie die Dockingstation verwenden, um den Leistungsumfang Ihres Tablet PCs zu erweitern. Interpretieren der Statuslämpchen Die Lämpchen an der Vorderseite der Dockingstation zeigen den Status an. Statuslämpchen Grün: Der Tablet PC ist angedockt.
Einsetzen und Entnehmen des Tablet PCs Sie können den Tablet PC ganz einfach in die Dockingstation einsetzen und ihn wieder entnehmen. So setzen Sie den Tablet PC ein • Setzen Sie den Tablet PC vorsichtig in die Dockingstation ein. Der Tablet PC rastet ein, wenn er richtig eingesetzt ist. Das grüne Docking-Lämpchen zeigt eine erfolgreiche Verbindungsherstellung an.
So entnehmen Sie den Tablet PC Es gibt zwei Möglichkeiten, den Tablet PC aus der Dockingstation zu entnehmen: • Drücken Sie den Auswurfknopf und ziehen Sie den Tablet PC dann aus der Dockingstation. Auswurfknopf • Halten Sie die Dockingstation mit einer Hand fest und ziehen Sie den Tablet PC aus der Dockingstation.
Wenn die Dockingstation lediglich zum Laden des Akkus des Tablet PCs oder des Ersatzakkus verwendet wird, stellen Sie den Sichtwinkel auf 15° ein. Auf diese Weise sparen Sie Platz und erhöhen die Stabilität. Wenn der Tablet PC in die Dockingstation eingesetzt ist und Sie mit der Tastatur arbeiten möchten, stellen Sie den Sichtwinkel auf 25°...
Verwendung eines externen Monitors und Projektors Sie können die Dockingstation für Präsentationen mit einem VGA-(Video Graphics Array-)Monitor oder einem Projektor verbinden. Ihr Tablet PC unterstützt unterschiedliche Konfigurationen externer Monitore, beispielsweise die erweiterte und gespiegelte Anzeige. So verwenden Sie einen VGA-Monitor 1.
Verwendung des Akkuladeschachts Im Akkuladeschacht an der Rückseite der Dockingstation können der Tablet PC und ein Ersatzakku gleichzeitig geladen werden. • Wenn Sie den Tablet PC laden möchten, setzen Sie ihn in die Dockingstation ein. • Wenn Sie einen Zusatzakku laden möchten, setzen Sie einen Akku in den Akkuladeschacht ein.
Tablet PC eingeschaltet ist und sich in der Dockingstation befindet. ACHTUNG: (Nur die Modelle CFT-001 und CFT-002) Sie dürfen den Tablet PC keinesfalls herausnehmen und die Verbindung des Tablet PCs mit dem Docking-Anschluss der Dockingstation trennen, da hierdurch die Stromversorgung des Tablet PCs unterbrochen wird.
Garantie Dieses Produkt unterliegt einer eingeschränkten Gewährleistung. Weitere Einzelheiten zu dieser eingeschränkten Gewährleistung finden Sie unter www.motioncomputing.com. Sicherheit und Vorschriften Allgemeine Sicherheitsinformationen finden Sie im Sicherheits- und Vorschriftshandbuch zu Ihrem Tablet PC. FCC-Erklärung (USA): Die Prüfung dieses Geräts hat ergeben, dass die Grenzwerte für ein digitales Gerät der Klasse B, gemäß...
(IEC 61000 3-3), EN60950 (IEC 60950 3. Ausgabe; 1999; 2000). Service und Support Für Service und Support besuchen Sie: www.motioncomputing.de/support. Patente Die Motion Computing-Produkte und -Dienstleistungen können einem oder mehreren geschützten Erfindungen unterliegen. Weitere Informationen finden Sie unter www.motioncomputing.com/info/patents.asp. Dockingstation...
Estación base Este documento se aplica a la estación base de los modelos de Tablet PC CFT-001, CFT-002 y CFT-003. Para determinar de qué modelo de tablet dispone, consulte la etiqueta que se encuentra en la parte trasera de la unidad.
Colocación y montaje de la estación base Puede colocar la estación base sobre una mesa o escritorio, o montarla en una pared, un carro, un brazo de montaje u otro equipo. La parte inferior de la estación base dispone de un patrón de montaje VESA estándar que puede utilizar con otros equipos VESA compatibles.
Montaje en un carro o brazo de montaje El montaje de la estación base en un carro o brazo de montaje requiere un montaje compatible con VESA para que se ajuste al patrón de orificio VESA de 75 mm de la parte inferior de la estación base.
Conexión de la estación base La estación base incluye puertos para ampliar las funciones de su tablet así como para cargar la batería. Para conectarse a los puertos de la estación base 1. Conecte el adaptador de alimentación como se muestra en la siguiente ilustración.
Page 55
2. Conecte los periféricos como un teclado o ratón a los puertos USB. Nota: Los puertos de la estación base pueden recibir alimentación a través de la batería del tablet o por alimentación de CA. Puerto de alimentación de CA Puertos USB Puerto Ethernet Ranura de seguridad Puerto...
Uso de la estación base Una vez que haya montado la estación base y conectado los periféricos, puede utilizar la estación base para mejorar el rendimiento de su tablet. Lectura de las luces de estado La luces ubicadas en la parte delantera de la estación base indican su estado.
Acoplamiento y retirada del tablet Puede insertar y retirar el tablet fácilmente de la estación base. Para acoplar el tablet • Deslice suavemente el tablet sobre la estación base. El tablet queda bloqueado en su sitio cuando está acoplado de forma correcta.
Para retirar el tablet Puede retirar el tablet de la estación base de dos formas: • Pulse el botón de expulsión y luego retire el tablet de la estación base. Botón de expulsión • Sujete la estación base con una mano y retire el tablet de la estación base.
Bloqueo de la estación base La ranura de seguridad sólo bloquea la estación base, no el tablet. Para bloquear la estación base 1. Localice la ranura de seguridad en la estación base. Ranura de seguridad 2. Abra y coloque su cierre en la ranura de seguridad. 3.
Uso de un monitor y proyector externos Para las presentaciones, puede conectar la estación base a un proyector o monitor VGA. El tablet admite varias configuraciones del monitor externo, incluyendo pantallas duplicadas y ampliadas. Para utilizar un monitor VGA 1. Conecte el cable del monitor al puerto VGA de la estación base.
Uso de la bahía de carga de la batería La bahía de carga de la batería de la parte trasera de la estación base le permite cargar el tablet así como una batería de repuesto al mismo tiempo. • Para cargar el tablet, colóquelo en la estación base. •...
Puede cambiar la batería en el tablet mientras está encendido y acoplado. ADVERTENCIA: (Modelos CFT-001 y CFT-002 únicamente) Evite levantar y desconectar el tablet del conector de base que hay en la estación base, ya que causará una pérdida de alimentación del tablet.
Garantía Este producto cuenta con una garantía limitada. Para ver los detalles de esta garantía limitada, visite www.motioncomputing.com. Seguridad y normativa Para obtener información general de seguridad, consulte la guía de seguridad y normativa incluida con su tablet. Aviso de la comisión federal de comunicaciones (FCC) (Estados Unidos): Este equipo ha sido probado y cumple con los límites establecidos para dispositivos digitales de Clase B, de conformidad con el Apartado 15 de la Normativa de la FCC.
3), EN60950 (IEC 60950 3rd Ed; 1999; 2000). Servicio y asistencia Para obtener servicio y asistencia, visite www.motioncomputing.es/support. Patentes Los productos y servicios de Motion Computing pueden estar cubiertos por uno o más inventos protegidos. Para obtener más información, visite www.motioncomputing.com/info/ patents.asp.
Base de encaixe Este documento aplica-se às bases de encaixe para modelos de Tablet PC CFT-001, CFT-002 e CFT-003. Para determinar qual modelo de tablet você tem, consulte a etiqueta na parte de trás do aparelho. A base de encaixe adiciona funcionalidades ao seu tablet, incluindo expansão de portas para Ethernet, monitores VGA...
Posicionando e montando a base de encaixe É possível posicionar a base de encaixe em uma mesa ou escrivaninha, ou montá-la em uma parede, carrinho, braço de montagem ou outro equipamento. A parte de baixo da base de encaixe possui uma montagem do padrão VESA, que pode ser usada com outros equipamentos compatíveis com esse padrão.
Montagem em um carrinho ou braço de montagem A montagem da base de encaixe em um carrinho ou braço de montagem requer uma montagem compatível com VESA para que seja possível fazer a conexão com o orifício VESA de 75 mm na parte de baixo da base de encaixe.
Conectando a base de encaixe A base de encaixe inclui portas para estender os recursos do seu tablet e recarregar a bateria. Para conectar-se às portas da base de encaixe 1. Conecte o adaptador de corrente conforme exibido na ilustração a seguir. Base de encaixe...
Page 69
2. Conecte os periféricos, como o teclado ou o mouse, nas portas USB. Nota: As portas da base de encaixe podem ser alimentadas pela bateria do tablet ou pela fonte de alimentação CA. Portas da fonte de alimentação CA Portas USB Porta Ethernet Encaixe de segurança Porta VGA...
Usando a base de encaixe Após montar a base de encaixe e conectar os periféricos, é possível usá-la para melhorar o desempenho do seu tablet. Leitura das luzes de status As luzes na parte da frente da base de encaixe indicam seu status. Luzes de status Verde: tablet na base.
Colocando e removendo o tablet da base de encaixe É possível colocar e remover facilmente o tablet da base de encaixe. Para colocar o tablet na base • Com cuidado, deslize o tablet na base de encaixe. Quando posicionado corretamente, o tablet encaixa e prende na base com segurança.
Para remover o tablet da base É possível remover o tablet da base de encaixe de duas maneiras diferentes: • Pressione o botão de ejetar e retire o tablet da base de encaixe. Botão de ejetar • Segure a base de encaixe com uma mão e retire o tablet com a outra.
Para usar o teclado com um tablet posicionado na base de encaixe, ajuste o ângulo de visualização para 25º ou 38º. Travando a base de encaixe O encaixe de segurança trava somente a base de encaixe, e não o tablet. Para travar a base de encaixe 1.
Usando um monitor ou projetor externo É possível conectar a base de encaixe a um monitor VGA ou a um projetor para realizar apresentações. O tablet suporta diversas configurações de monitores externos, incluindo monitores espelhados e estendidos. Para usar um monitor VGA 1.
Usando a base de carregamento da bateria A base de carregamento da bateria na parte de trás da base de encaixe permite que você recarregue o tablet e uma bateria extra ao mesmo tempo. • Para recarregar o tablet, posicione-o na base de encaixe. •...
É possível trocar a bateria do tablet enquanto ele estiver na base de encaixe. AVISO: (Somente modelos CFT-001 e CFT-002) Evite erguer o tablet e desconectá-lo do conector da base de encaixe, pois isso causará perda de energia no tablet.
Garantia Este produto é fornecido com um garantia limitada. Para obter mais detalhes sobre a garantia limitada, visite o site www.motioncomputing.com. Segurança e normas Para obter informações gerais de segurança, consulte o Guia de Normas e Segurança que foi enviado junto com o seu tablet. Notificação FCC (Estados Unidos): Este equipamento foi testado e está...
Serviço e suporte Para serviço e suporte, visite o site www.motioncomputing.pt/support. Patentes Os produtos e serviços da Motion Computing podem estar cobertos por uma ou mais invenções protegidas por patentes. Para obter mais informações, consulte o site www.motioncomputing.com/info/patents.asp. Base de encaixe...
