The C5v/F5v 10.4" XGA display has a resolution of 1024 X 768.
tablet PC
Extended with tablet primary
The "extended with tablet primary" display theme expands the desktop area across the
tablet and external monitor, with the tablet is primary display. You can set the external
monitor to use a different display resolution than the tablet.
Monitor only
The "monitor only" display theme uses the external monitor only.
Tablet only
The "tablet only" display theme uses the tablet display only.

Connect an external monitor

To connect an external monitor to the C5v/F5v, you use the CFT-Series docking station, sold
separately.
To set up an external monitor
1. Connect the monitor cable from the external monitor into the CFT-Series docking station
according to the CFT-Series Docking Station User's Guide.
2. Plug in the external monitor and turn it on.
3. If necessary, install software and drivers for the monitor. See the manufacturer's
documentation for more information.
4. Open
5. Tap Display.
6. Select a Display Scheme.
7. If your tablet PC does not respond to touch, follow the steps below to
the correct
Chapter 2 Using your C5v/F5v
Extended with monitor primary
Motion Dashboard
.
display.
external monitor
enable touch on
Setting display options 31
