Getting Started with the Motion® C5v/F5v Tablet PC
Locking and unlocking
Sleep
Place your tablet PC in sleep mode when you go away for a
short period of time to conserve battery power. When you re-
turn, the tablet PC quickly resumes activity and your desktop
is the same as you left it.
To put the tablet PC in sleep mode, press and release the
power button
. To wake up the tablet PC from sleep
mode, press the power button again.
t
The power button blinks when in sleep mode.
ip

Power on and off

Shut down your tablet PC from Windows. Tap the Start menu
then tap Shut down. If Windows does not respond at all,
force the tablet to shut down by pressing the power
button
for about five seconds.

Using the fingerprint reader

The C5v/F5v comes with a fingerprint reader so that you can
log on to your tablet PC by scanning your fingerprint instead
of entering a password. This not only provides an added level
of security for your tablet PC, but it is also a fast and conve-
nient way to log on.
1
To lock and unlock your tablet,
press the Security button
on the right side of the
tablet PC. It's equivalent to
pressing Ctrl+Alt+Delete.
t
: For information on using the
ip
front buttons, see page 2.

Using the pen

An important difference between traditional PCs and tablet
PCs is that you frequently use a digitizer pen instead of a
mouse and keyboard. A pen can feel more natural in your
hand than a mouse and you can use the pen while standing
or walking. The C5v/F5v pen has a pressure-sensitive tip,
eraser, and a function button. Pressing the function button
is equivalent to right-clicking a mouse.
function button
(right-click)
Pen tip
Using touch
(optional feature for F5v only)
N
: Touch is an optional feature for the F5v Tablet PC.
ote
In addition to using a pen, your F5v Tablet PC may be
equipped with "touch,"which means you can use your fingers
to select items and open files, zoom in and out, scroll through
browser windows and documents and more.
Touch works like a mouse. Tap to select an item and double-
tap to open it.
t
To open a right-click menu using touch, press your
ip
finger on the display until a swirl appears, then lift your
finger and the shortcut menu appears.
Calibrate the pen and your finger so that they can be detect-
ed more accurately on the touchscreen display. You should
do so when you first start using the tablet PC and when the
pointer doesn't align with your pen or finger. To start the ap-
plication, open the Motion Dashboard Pen & Tablet category
(see page 4).
Model CFT003
eraser
C5v/F5v Getting Started
