Right Side - Motion Computing C5v User Manual

Right side

power adapter
port, USB port (F5v),
and cover
Chapter 1 Getting Started
Windows security
RFID antenna
area
Power adapter Connect the power adapter.
port, USB port (F5v
only), and cover
RFID (optional) Scan area for reading RFID tags.
antenna area
Camera (optional) Use to trigger the built-in documentation camera.
button
Windows Security Use to log on to or lock the tablet. Equivalent to
button Ctrl+Alt+Del on a keyboard.
Fingerprint reader Scan your fingerprints for added security. You can also
use the fingerprint reader as a navigation device.
Power button Turns the tablet on and off.
Barcode scanner Reads codes from barcode labels.
(optional)
button
camera fingerprint
button reader
power
button
barcode scanner
Overview of the C5v/F5v 5
